Classification : Blow Molding Machine
Country: Taiwan
Phone: 886-4-22777457
Fax: 886-4-22777455
Contact Person: Jean Lin
This model of one-stage, three station in ection stretch blow molding machine is made by KAI MEI plastic machinery co. Itd. It has the possibility to economically produce high quality contain ers using various of many kinds of material in PET,PP,PC,TRITAN,PES,etc. and save energy. It lets our customers obtain the most profits with the fast cycle time from this injection stretch blow-molding machine.
PROCESSING WITH 3 STATION ROTARY TABLE
The process of this machine is by using a rotary disk to cycle three stations. At the first station,there is a high clamping force on the inection mould of this machine to ensure obtaining a good performace quality. At the second station, we assigned a controller to adjust the temperature so that our customers could obtain the best quality bottles. At the third station, it is in process of the stretching and high pressure blowing shape. At the last station,high quality bottles can be easily taken out.Model No. | UNIT | MIB 75 | MIB 65 | MIB 55 | MIB 45 |
Screw Dia. | mm | 75 | 65 | 55 | 45 |
lnjection Capacity | cm3 / shot | 884 | 565 | 333 | 175 |
Screw Heating Capacity | kw | 12.5 | 10 | 7 | 4.2 |
lnjection Clamping Force | ton | 102 | 102 | 61 | 33 |
Blowing Mold Clamping Force | ton | 55 | 43 | 34 | 18 |
Maximum Blowing Air Pressure | bar | 30 | 30 | 30 | 30 |
Air Pressure System | bar | 8 | 8 | 8 | 8 |
Hydraulic Pack Pump Motor | hp | 75 | 60 | 50 | 40 |
Operating Hydraulic Pressure (max) | kg / cm2 | 140 | 140 | 140 | 140 |
Total power consumption | kw | 82.5 | 64.5 | 50.5 | 35 |
Machine Size | LxWxH(M) | 6.5*3.4*5 | 5.8*3*4.7 | 5.4*2.4*4.2 | 4.5*2.0*3.4 |
Machine weight | ton | 20 | 16 | 11 | 7 |
*For more detailed information, please contact manufacturer.
*All specifications and designs are subject to change without notice.
