Horizontal Blow Molding Machines

Products
Double L-Ring Drum Blow Molding Machine
Double L-Ring Drum Blow Molding Machine

Categories : Horizontal Blow Molding Machines

Double L-Ring Drum Blow Molding Machine Double L-ring drums are very popular for the storage of dangerous liquids for the chemical industry. They are made of HMW HDPE, which has antiacid, alkali, and impact resistance characteristics in order to adapt to different conditions and climates. This advanced plastic drum making machine assures a perfect L shape and has a special cooling process for drum strengthening. Moreover, we make three times complete drop tests from a height of 1.5m by the front (neck part), body, and angle to ensure quality. In this machine, you are looking for unbeatable performance in every aspect. These machines are suitable for containers up to 250L.

Automatic Blow Molding machine- A Series
Automatic Blow Molding machine- A Series

Categories : Automatic Blow Molding Machines

This type is the pneumatic-clamping blow-molding machine, suitable for making popsicle (ice-lolly) & various small-size bottles. Extrusion is driven by the inverter motor with pulley-drive gear box. Innovative design for double die head production. Mold clamping is driven by pneumatic system, available for upgrading to hydraulic-drive system (Option). Carriage movement is the swing movement for taking the finished products from the front of the machine. Independent electric control box with simple control panel. Simple-type blow molding machine, suitable for low and initial blow molding machinery investment.

PET Fully Electric Stretch Blow Molding Machine Series for Cosmetics Bottles
PET Fully Electric Stretch Blow Molding Machine Series for Cosmetics Bottles

Categories : Electric Blow Molding Machines

PET Fully Electric Stretch Blow Molding Machine Series for Cosmetics Bottles

Pneumatic Extrusion Blow Molding Machine
Pneumatic Extrusion Blow Molding Machine

Categories : Automatic Blow Molding Machines

This series machine with special features which is designed especially for producing the drug bottle, toy, popsicle and etc. This type of machine can produce various material such as PP, PE, PVC. This is the most economical and high performance machinery nowadays.

PET Stretch Blow Molding Machine - TEM08S2
PET Stretch Blow Molding Machine - TEM08S2

Categories : Automatic Blow Molding Machines

● Adopt the touch screen control system with 64K color and friendly PLC operation. ● Exclusively designed machine construction makes it convenient to combine the blow molding machine with conveyor system. ● The preforms are automatically arranged in order for feeding system at a single way and the dividing carrier is driven by a servo motor; this way will avoid preforms jamming, causing machine down or preforms waste. ● Adopt a servo control screw driving system; it is rapid, stable, clean and environmentally friendly. ● The preforms are fed into the heating system in a matrix mode and uniform heated by single-lamp with double-sided heating. ● Employ a single-lamp with double-side heating design and will save about 50% heating consumption compared with competitor method. ● With the temperature feedback function, temperature in the heating oven is automatically controlled by adjustment of infrared lamps to reduce prefrom crystallization problems. ● Specially designed heating box upgrade convenience of maintenance in changing infrared lamp and cooling ramp. ● The clamping mechanism is driven by a combination of servo motor and cam; this results in accurate and stable motion, low noise and minimal pollution. ● Utilizes the air recovery system and efficiency up to 50% so that the low-pressure air compressor will not be required. This will save equipment investment costs and energy consumption by up to 15%.

Semi-auto Stretching Blow Molding Machine
Semi-auto Stretching Blow Molding Machine

Categories : Automatic Blow Molding Machines

Semi-Auto Stretching - Blow Molding Machine The semi-auto reheat stretch blow molding machine includes a rotary heater and blowing unit for a 2-step process: The rotary heater unit for softening the preform The blowing unit to extend the soft preform laterally and form the product The most commonly used materials are PMMA, PS, and AS. This machine is very popular for making transparent goblets, kettles, big jars, and food storage containers.

Pneumatic Extrusion Blow Molding Machine - Rotary Type
Pneumatic Extrusion Blow Molding Machine - Rotary Type

Categories : Automatic Blow Molding Machines

This machine is mainly suitable for plastic package with being blow up from side. Such as the plastic bottles for ice lolly, popsicle, or frozen bar. The main character of this machine is its simplicity & stabilization of operation. It has been famous for its excellent performance, low maintenance ratio, less consumption of electricity & low noise.

Automatic Blow Molding machine- O Series
Automatic Blow Molding machine- O Series

Categories : Horizontal Blow Molding Machines

Single Die Head or Double Die Heads and Single Station Type, Suitable for View Stripe Containers, Equipped with Auto Conveyor, and Leaking Tester for Quality Supervision.

PET Stretch Blow Molding Machine - TEM12S2
PET Stretch Blow Molding Machine - TEM12S2

Categories : Automatic Blow Molding Machines

Blower power consumption for 1000 bottles: 2Wh Air Compressor power consumption for 1000 bottles: 6 kWh compact space Screw driven controlled by servo motor providing fast and smooth motion Single lamp bilateral centralized heating, easy controlled within 3°C and energy heating Low-pressure air compressor will NOT be required due to high-pressure recovery system. High efficient air recovery system up to 45%

Blow Molding Machine PBS-305~505 Series
Blow Molding Machine PBS-305~505 Series

Categories : Horizontal Blow Molding Machines

Custom design is avaiable to suit various plastic materials such as PE, PP, PVC, PS, PC and nylon. Designed for producing medium and small sized containers.

PET Stretch Blow Molding Machine (FCP Series)
PET Stretch Blow Molding Machine (FCP Series)

Categories : Automatic Blow Molding Machines

Grouping Brand Parts Internationalization Apply for Small Production Line Complete Online Consultation Service QR code Intelligent Management Networkable Machine (Optional)
