Pipe Crusher

Classification : Plastic Crusher & Shredder

GENIUS MACHINERY CO., LTD.

GENIUS MACHINERY CO., LTD.
Country: Taiwan
Phone: 886-4-2630-1621
Fax: 886-4-2630-1716
Contact Person: Peter Tsai
Our machines are equipped with hydraulic opening for easy cleaning, with special design characteristics of rotator knife wheel offers large cutting angle, require less space. Thick walled sections are specially designed on tops and tails to process any typical waste like molded items, pipes, profiles, films, sheets and etc.
Model

Rotor Diameter(mm)

Rotor Lenth(mm)

Enterance Size(mm)

Main Drive

Screen Size(mm)

Capacity(Kg/Hr)

GP-380

380 500 300×300 20~60HP(15~45KW) >6 400~1200
GP-500 500 500~1200 500×1000 40~100HP(30~75KW) >6 500~1200
GP-600 600 800~1600 600×1000 60~150HP(45~110KW) >10 800~1600
GP-800 800 1000 800×1200 100~200HP(75~150KW) >10 1200~2000

Materials before process




Materials after process
