Fully Automatic Loop Handle, Die Cut Handle & Draw Tape Bags Making Machine LY-800LDD
Classification : Shopping Bags
LIAN YOU MACHINERY INDUSTRY CO., LTD.

Country: Taiwan
Phone: 886-3-3490269
Fax: 886-3-3490220
Contact Person: Nicole Hung
Introduction
LY-800LDD is a high-speed, triple-function bag making machine which can produce soft-loop bag, draw-tape bag and die cut bag.The unique control of servo-feeding system allowing customer having stable production and the human-machine interface lets customers never worry about operation.
Features
-
Specialize in soft-loop, die-cut and draw-tape bags.
-
Servo-driven feeding system with one set of photocell for printed bag.
-
Human-machine interface for easy setting.
- Specialize in soft-loop, die-cut and draw-tape bags.
- Servo-driven feeding system with one set of photocell for printed bag.
- Human-machine interface for easy setting.
Model
Size
Max. Production Speed
Cycles / Min
Thickness of Film (mm)
Heaters
Width
Length
Top Gusset
Bottom Gusset
LY-800LDD
250-540mm
250-650mm
70-75mm
up to 85mm
40-100
0.04-0.1
2.6KW x 1 0.8KW x 2
0.3KW x 4 0.4KW x 4
Model
Power Required
Machine Dimensions
Machine Weight (kg)
Packing Size (M)
Gross Weight (KG)
Air Compressor
(not included)
L(M)
W(M)
H(M)
LY-800LDD
8.8KW
7.6
3.2
1.85
3500
5.8 x 2 x 2
4000
10HP
Notes:due to continual research and improvement, mechanical specifications are subject to further revision without prior notice.
Model |
Size |
Max. Production Speed
|
Thickness of Film (mm) |
Heaters |
|||
---|---|---|---|---|---|---|---|
Width |
Length |
Top Gusset |
Bottom Gusset |
||||
LY-800LDD |
250-540mm |
250-650mm |
70-75mm |
up to 85mm |
40-100 |
0.04-0.1 |
2.6KW x 1 0.8KW x 2
|
Model | Power Required | Machine Dimensions | Machine Weight (kg) | Packing Size (M) | Gross Weight (KG) |
Air Compressor (not included) |
||
---|---|---|---|---|---|---|---|---|
L(M) | W(M) | H(M) | ||||||
LY-800LDD | 8.8KW | 7.6 | 3.2 | 1.85 | 3500 | 5.8 x 2 x 2 | 4000 | 10HP |
