Classification : Heavy Duty Bags
Country: Taiwan
Phone: 886-3-3490269
Fax: 886-3-3490220
Contact Person: Nicole Hung
Introduction
- LY-650BF/800BF/1000BF series are free-tension heavy duty bag making machine, its 3-sets servo control system allowing customer to make very thick bag with good quality of sealing. All series have HMI system for easy operation.
Features
- Free-tension, heavy -duty bottom sealing bag making machine.
- Servo-driven feeding system with one set of photocell for printed bag.
- Servo-driven flying knife system for cutting.
- Servo-driven sealing bar for good quality of sealing.
- Human-machine interface for easy setting.
| Model | Bag Size | Production Speed Cycles / Min | Thickness / 1 Sheet (mm) | Heaters | Power Required | |
|---|---|---|---|---|---|---|
| Width (mm) | Length (mm) | |||||
| LY-650BF | 650 | 1200 | 10-60 | 0.04-0.20 | 2.6KW x 2 | 6KW |
| LY-800BF | 800 | 1200 | 10-60 | 0.04-0.20 | 2.6KW x 2 | 6.5KW |
| LY-1000BF | 1000 | 1200 | 10-60 | 0.04-0.20 | 3KW x 2 | 7KW |
| Model | Machine dimensions | Machine Weight (kg) | Packing Size(M) | Gross Weight (kg) | Air compressor (Not included) |
||
|---|---|---|---|---|---|---|---|
| L(M) | W(M) | H(M) | |||||
| LY-650BF | 5.5 | 1.4 | 1.4 | 1500 | 3.0 x 1.6 x 1.5 | 1800 | 5HP |
| LY-800BF | 5.5 | 1.5 | 1.4 | 1800 | 3.0 x 1.8 x 1.5 | 2100 | 5HP |
| LY-1000BF | 5.5 | 2 | 1.4 | 2100 | 3.0 x 2.0 x 1.5 | 2400 | 5HP |
Notes：due to continual research and improvement, mechanical specifications are subject to further revision without prior notice.
