Classification : Bag Making Machine
Country: Taiwan
Phone: 886-5-221-7967
Fax: 886-5-221-7996
Contact Person: Eric Kuo
Model | 32 | 32 | 32 | 42 | 42 | 42 |
2 wire | 3 wire | 4 wire | 2 wire | 3 wire | 4 wire | |
Machine dimension (cm) |
L : 230 W : 153 H : 195~230(-35) |
L : 230 W : 178 H : 195~230(-35) |
||||
Machine center (m/m) |
410 | 270 | 200 | 500 | 330 | 250 |
430 | 530 | |||||
Packing width (m/m) |
130~350 | 130~220 | 130~150 | 130~450 | 130~280 | 130~200 |
Packing length (m/m) |
230~580 | 230~580 | 230~580 | 230~580 | 230~580 | 230~580 |
Feed sensor (SET) |
2 | 3 | 4 | 2 | 3 | 4 |
Printer sensor (SET) |
2 | 3 | 4 | 2 | 3 | 4 |
Fastest speed (Cycles / Min) |
10 | |||||
Outer bag MAX Diameter (m/m) |
500 | |||||
Total power (kw) |
6.5 | |||||
Voltage (v) |
220 | |||||
Outer bag thickness (m/m) |
0.025 |
Improve the overall productivity of shopping bags for reducing labor intensity.
Automated production from film roll-in-sealing-cut-bag-punching-fold-folding.
# Improve quality yield rate
.full servo system connection
# Raise resources for recycling
.1 person responsible for 2-3 sets of bag making machines
# Raise the concept of environmental protection resources
.Packing line production
.Reduce 1-3 bottom sealers
.Reduce sealing heat source
# Space Reuse
.Reduce bagged finished products and transport them to packaging area
.Products which directly shipping after the automatic packaging machine
Automated production from film roll-in-sealing-cut-bag-punching-fold-folding.
# Improve quality yield rate
.full servo system connection
# Raise resources for recycling
.1 person responsible for 2-3 sets of bag making machines
# Raise the concept of environmental protection resources
.Packing line production
.Reduce 1-3 bottom sealers
.Reduce sealing heat source
# Space Reuse
.Reduce bagged finished products and transport them to packaging area
.Products which directly shipping after the automatic packaging machine
