Classification : Drying & Dehumidifying System
Country: Taiwan
Phone: ENGLISH: 886-4-2271-0000 | 中文：886-4-22716999
Fax: 886-4-2271-1988
Contact Person: Bunny Tsai
Oven Dryer (YBO)
The Oven Dryer is a compact, convenient drying equipment which can dry more than one type of resin at the same. For plastics use, it can be used for annealing and product testing after molding.
- It can also dry electric motor and parts, electroplating, pharmaceutical, paint, printing, agricultural and food. (grain, garlic, tea, and etc.)
-
Powerful, heated air flow system and unique air circuit are designed for evenly temperature control and the best baking quality.
-
The oven dryer has stainless steel trays in which you can place your resins or material to be dried. Hot air recycling system is durable and energy saving.
-
Equipped with 24-hour-timer which can be set in advance to operate the oven dryer.
| Oven Dryer (YBO) | |||||||||||||
| Model | Internal Dimensions WxDxH | External Dimensions WxDxH | Motor | Number of Trays | Tray Dimensions WxDxH | Material of Trays | Approx. Weight | Capacity | Material | Temperature Range | Accuracy | Options | |
| cm | cm | kw | kw | cm | kg | kg | |||||||
| YBO- 2-B | 81x60x73 | 109x80x144 | 0.375 | 5(1x5) | 7 | 79x59x5 | SUS 430 | 180 | 52 | SS41(SS41 Steel Plate) | 40℃-180℃ | ±1.5% | 1.PID TEMP. CONTROLLER 2.WHEELED TRAYS |
| YBO- 4-B | 81x60x113 | 114x85x186 | 0.75 | 6(1x6) | 12 | 79x59x5 | 200 | 125 | |||||
REMARKS
- For the best result, please choose the model according to 90% of the capacity.
- Please do not place any objects on the top of the oven dryer.
- We reserve the right to change the technical data without prior notice.
