Twin Screw Side Feeder-PSC
Categories : Dosing, Measuring & Mixing Equipment
The PSC series twin-screw side feeder was developed by Sino-Alloy Machinery as an important accessory to their extruder line. Its design is based on Sino-Alloy’s years of experience. The PSC twin-screw side feeder has a large feeding screw chamber for a smooth flow of the feeding material. The intermeshed type twin-screw has a self-cleaning feature with powerful displacement force, high feed volume, stable feeding, and excellent aeration properties, making it suitable for moist, low coefficient of friction powders and mixed types of plastics which require forced side feeding. Sino-Alloy Machinery can also tailor the design of a PSC twin-screw side feeder to match extruders from other manufacturers. Customers can also specify options such as preheating or cooling to suit production needs.
Twin Screw Feeder-PSB
Categories : Dosing, Measuring & Mixing Equipment
The PSB series twin-screw feeder was developed by Sino-Alloy Machinery as an important accessory to their extruder line. Its design is based on Sino-Alloy’s years of experience. The PSB twin-screw feeder has a large feeding screw chamber for a smooth flow of the feeding material. Screw options include intermeshed, T-type, and single-flight screws, which can be swapped easily and quickly to match the feeding material. The advantages of the intermeshed type of screw pairs are powerful displacement right-angle conveying, self-cleaning of the screws, high feed volume, and stable feeding. The deeper and wider groove from a single-flight conveyor, T-type, or non-intermeshed screw is more suited for particulate, flake, fiber, or powder feeding. Sino-Alloy can also tailor the design of the feeder to match extruders from other manufacturers. Customers can also specify options such as premix, vibrate, preheat or cooling to suit production demands.
Taper Screw Batch Pre-former
Categories : Rubber Mixing & Pre-Processing Equipment
FUNCTION: This uniquely designed Taper Twin Screw Extruder has a large volume open top hopper, which will accept a whole batch from your mixer without performing. The twin screws continuously and automatically bite and feed the compound, which then is extruded through a die. This simple but effective feeder, allows you to eliminate many labor intensive material handing processes, between your mixer and existing conventional extruders or other equipments.. BENEFITS: Large volume hopper capacity Exceptional cooling and temperature control Full and easy access for cleaning Simple, automatic and continuous operation Easy maintenance Cost effective and affordable
STRETCH FILM LDPE/LLDPE PLASTIC INFLATION MAKING MACHINE : KML-45S/55S
Categories : Blown Film Extruders Lines
The KML-45S/55S is a stretch film plastic inflation making machine that converts LDPE/LLDPE pellets into stretch film through blown film extrusion, with adjustable film thickness and width. The KML-45S runs an Ø45mm screw at a 30:1 L/D ratio with a 20 HP AC driving motor, producing film up to 600 mm wide at 20-55 kgs/hr; the KML-55S runs an Ø55mm screw at the same ratio with a 30 HP AC driving motor, producing film up to 900 mm wide at 30-72 kgs/hr. Both models include an auto tension controller, waste collecting winder, and adhesives auto-feeder. Models: KML-45S / KML-55S Suitable material: LDPE/LLDPE (both) Film thickness: 0.008-0.10 mm (both) Film width range: KML-45S 600 mm; KML-55S 900 mm Film output: KML-45S 20-55 kgs/hr; KML-55S 30-72 kgs/hr Screw diameter/type: KML-45S Ø45mm; KML-55S Ø55mm (L/D ratio 30:1 both) Driving motor: KML-45S AC 20 HP + Inverter; KML-55S AC 30 HP + Inverter Equipment: Auto tension controller, waste collecting winder, adhesives auto-feeder Take-up speed: KML-45S 75 m/min; KML-55S 65 m/min
Side Sealing Bag Making Machine (GF-32SE/SV)
Categories : Plastic Bag Making Machines
The GF-32SE/SV is a servo-driven side sealing bag making machine, the machine type used for clear packaging bags, garment bags and similar side-sealed formats. Within the series — GF-24SE/SV, GF-32SE/SV, GF-40SE/SV and GF-50SE/SV, with matching GF-S600/SV to GF-S1200/SV models — the GF-32SE/SV has a cutting width of 800 mm and a cutting length of 800 mm, on film from 0.01 - 0.1 mm. Production is Max. 200 Cycles/Min for the SE model and Max. 150 Cycles/Min for the S model. The rear feeder is supplied with gusset, fold, slitter and adhesive tape applicator functions, the control panel uses an HMI, and the servo drive is YASKAWA/JAPAN with a SICK/GERMANY printing scanner. A conveying belt and collecting table are included. Options extend the machine to tension control, EPC, a triangle folding device, punch hole and Mexican hat punch devices, ultrasonic sealing, a perforating sealing knife, an envelope punching mold and an automatic stacking table. Type: side sealing bag making machine, servo drive Series: GF-24SE/SV, GF-32SE/SV, GF-40SE/SV, GF-50SE/SV (GF-S600/SV to GF-S1200/SV) Cutting width: 800 mm; cutting length: 800 mm Film thickness: 0.01 - 0.1 mm Production: SE model Max. 200 Cycles/Min; S model Max. 150 Cycles/Min Rear feeder with gusset / fold / slitter / adhesive tape applicator; HMI control; servo YASKAWA/JAPAN; printing scanner SICK/GERMANY Options: tension control, EPC, triangle folding, punch hole, Mexican hat punch, ultrasonic sealing, perforating sealing knife, envelope punching mold, automatic stacking table
Side Force Feeder Type Double Section Recycling Pelletizing Extrusion Line | CK-SFD
Categories : Recycled Plastic Pelletizing Lines
CK-SFD series Side Force Feeder Type Plastic Recycling Pelletizing Line is ideal for recycling dirty plastic crushed films. Possible materials : EPE, EPP, EPS, PP, HDPE, LDPE, ABS, PS crushed films or flakes.
Side Force Feeder Type Recycling Pelletizing Extrusion Line | CK-SF
Categories : Recycled Plastic Pelletizing Lines
CK-SF series Side Force Feeder Type Plastic Recycling Pelletizing Line is ideal for recycling clean or washed plastic crushed films. Possible materials : EPE, EPP, EPS, PP, HDPE, LDPE, ABS, PS crushed films.
Side Feeder / Side Feeder Twin Screw
Categories : Dosing, Measuring & Mixing Equipment
CYKF developed its own twin screw side feeder to enable the feeding of additives and fillers, such as glass fiber, CaCO3, TiO2, Talc, fire retardant, etc. Materials in powder or pellet are all acceptable. Our rich experiences in plastic extrusion help us catch the critical design points to satisfy different production requirements.
Automatic Batch Weighing and Mixing System
Categories : Dosing, Measuring & Mixing Equipment
Automatically measuring equipment for efficient mix and material processing. Equip with auto conveying system, batching system, mixer, kneader, extruder and steel construction plant. Discharge feeder: scale screw feeder Automatically conveys material to extruder after mixing PC control monitoring system live network Complete installation of pulverizer series
Master-batch Feeder (MF)
Categories : Dosing, Measuring & Mixing Equipment
The masterbatch mixes with your virgin resin at the machine hopper automatically. You don't need to pre-color nor pre-mix your resin anymore. It saves the manpower, resin, stock costs, and keeps working environment clean. The unit mixes and doses masterbatch, additives, free flowing powders, regrinded and virgin resin to ensure consistent and accurate mixing which results in better quality of product and less rejects. With the special process, the internal part of the unit has no dead corners and makes the dosing process more accurate. Both dosing-cylinder and dosing-screw can be easily changed. The motor feedback control is operated by the tacho-generator which will not be influenced by power fluctuations. It gives the utmost accurate dosing. If some reasons changed R.P.M. of the extruder after setting, the unit will automatically to be changed by the percentage of new R.P.M. By just entering the weight of the materials, screw back time, dosing capacity per turn and additional rate of the masterbatch, the CPU will calculate proper R.P.M. rate automatically. The control panel is user friendly & much more accurate. Besides, it also has the function to store up to 10 sets of R.P.M. setting. To work with the injection molding machines, the unit is also equipped with a timer to control the dosing time.
Water Cooling Type Plastic Film Recycling Machine (GSR-100)
Categories : Recycling Lines by Application
The GSR-100 is the 100 mm size in JANDI'S GSR water cooling type plastic film recycling series for HD, LD and LLDPE and P.P. scrap. A spiral feeder delivers film into the 100 mm extruder, which is driven by a 60 HP motor; the melt passes a screen changer driven by an A.C. motor with reducer and leaves through a spaghetti type die head into a stainless steel water tank, where the strands are cooled before being blown dry and pelletized by a rotary cutter with fixed blade. Maximum capacity is 190KG/ HR. The GSR-100 sits between the GSR-85 and GSR-120 in a series of six sizes, from the GSR-45 with a 45 mm extruder and 15 HP motor to the GSR-150 with a 150 mm extruder and 100 HP motor. Control is from an independent switch board. The option list is shared across the series: conveyor with metal detector, crusher, screw conveyor, vacuum pump, pressure gauge, hydraulic screen changer, second extruder, vibrating screen, and air blower with storage tank. Type: water cooling (spaghetti type) plastic film recycling machine Material: HD/LD/LLDPE & P.P. Extruder: 100 mm; driving motor 60 HP Max. capacity: 190KG/ HR Feeding: spiral feeder; screen changer driven by A.C. motor with reducer; spaghetti type die head Stainless steel water tank and blower; rotary cutter with fixed blade Series: GSR-45 (45 mm, 15 HP) to GSR-150 (150 mm, 100 HP); options: conveyor with metal detector, crusher, hydraulic screen changer, 2nd extruder, vibrating screen
Water Cooling Type Plastic Film Recycling Machine (GSR-85)
Categories : Recycling Lines by Application
The GSR-85 is a water cooling type plastic film recycling machine for HD, LD and LLDPE and P.P. scrap. Film is fed by a spiral feeder into an 85 mm extruder driven by a 40 HP motor, passes a screen changer driven by an A.C. motor with reducer, and is extruded through a spaghetti type die head into a stainless steel water tank. The cooled strands are blown dry and cut by a pull and cutting unit with a rotary cutter and fixed blade, at a maximum capacity of 120 KG/HR. The GSR-85 is the mid-size machine in a series that runs from the GSR-45 to the GSR-150, with extruder sizes from 45 mm to 150 mm and driving motors from 15 HP to 100 HP. All sizes are controlled from an independent switch board. Options include a conveyor with metal detector, crusher, screw conveyor, vacuum pump, pressure gauge, hydraulic screen changer, second extruder, vibrating screen, and an air blower with storage tank. Type: water cooling (spaghetti type) plastic film recycling machine Material: HD/LD/LLDPE & P.P. Extruder: 85 mm; driving motor 40 HP Max. capacity: 120 KG/HR Feeding: spiral feeder; screen changer driven by A.C. motor with reducer; spaghetti type die head Stainless steel water tank and blower; pull and cutting unit with rotary cutter and fixed blade Series: GSR-45 to GSR-150 (45 mm to 150 mm, 15 HP to 100 HP); options: conveyor with metal detector, crusher, hydraulic screen changer, 2nd extruder, vibrating screen
Film Extrusion Molding Machine Auxiliary Solutions
Categories : Turnkey & Auxiliary Integration Solutions
We have a wide range of auxiliary equipment for film extrusion molding mechines, like hopper dryers, dehumidifying dryers, chillers, PET crystallizers, vacuum loaders, mold temperature controllers, master-bacth feeders and auto dosing and mixing systems. Better company image Greater productivity Lower cost Better energy efficiency Less material waste and pollution during the conveying process Better working environment Less noise due to the separation of the blowers from the working place
Feeder-Ruder Pellet Making Extruder
Categories : Recycling Lines by Application
Extrusion & Pelletizing for Rubber、Plastic & Chemical Industries This new model Feeder-Ruder Pellet Making Extruder usage for extruding and pellet making after Plastic or Rubber compound mixing in the Dispersion Kneader and conveying to the hopper of this machine. Pellets making method with mold Hot Face Cutting and Water ring cutting two kind.
Eddy Current Non-Ferrous Metal Separator Line
Categories : Washing & Classifying Lines
Rey Long's JLECS-1000W is a complete non-ferrous metal separation line combining three stages in one system: a vibratory feeder for material distribution, a high-intensity magnetic drum separator for ferrous removal, and an eddy current magnetic roller for precise non-ferrous metal recovery. Ideal for recycling plants, e-waste processing, and mixed-material sorting.
4.0G 10 Heads Multihead Weigher (3L)
Categories : Dosing, Measuring & Mixing Equipment
Multihead Weigher Working Principle The multihead weigher or computer combination weigher usually uses different weigh heads to measure the precise weight of the products. After the product is fed into the top of the multihead combination weigher, the internal distribution system of the weigher starts working. This system distributes the product. With the help of linear feed plates, different linear feeders will deliver some product into the feed hopper. For example, if you are using a 14-head multihead weigher machine, there will normally be 14 linear feeders that will deliver products to 14 feed hoppers. After the products are delivered to the hopper, the load cell begins to calculate the weight of the product in the weigh hopper, and the processor in the multihead weigher then calculates the best combination of available weights needed to achieve the desired target weight.
Master-batch Feeder for Powder (MFP)
Categories : Dosing, Measuring & Mixing Equipment
Easy operation: Enter the weight of the resins, screw back time, dosing capacity per turn and additional rate of the masterbatch, it will calculate proper R.P.M. rate automatically. The function is available to store up to 10 sets of R.P.M. Setting memory. Flexible extension: Each feeder controls and operates individually. It is easy to add extra a feeder or change the type of screw later. A dosing and mixing system of various resins is available for your early inquiry. Precise calculation: With the special process, the internal part of the unit has no dead corners and makes the dosing process more accurate.
Low-Speed Mixer-PSE
Categories : Mixers and Blenders
The PSE low-speed mixer is a frequently used accessory for the PSM series co-rotating twin-screw extruder. Raw material does not heat up in the mixer which is beneficial to its stability. After the premix stage the material can be fed to the extruder via one of our PSA single-screw feeders, PSB twin-screw feeders, PSC twin-screw side feeders, or the PSD single-screw force feeder. Also compatible with feeders from other manufacturers or gravimetric loss-in-weight feeding systems.
Single Screw Type Loss-in-Weight Feeder
Categories : Dosing, Measuring & Mixing Equipment
Loss-In-Weight Feeder is a precision feeding device designed specifically for handling granular or free-flowing powdered materials. Utilizing advanced technology, this feeder is capable of delivering maximum accuracy at minimal feed rates, meeting the precise ingredient requirements in different industries.
Loss-In-Weight Feeder
Categories : Dosing, Measuring & Mixing Equipment
Loss-in-weight feeder is a gravimetric metering device that provides continued feeding without cause batch problems. The feeder receives constant feedback from the sensor to ensure the materials are delivered in a precise amount that saves manpower successfully. CYKF provides different types of loss-in-weight feeders, including single screw, twin screw, and the models for feeding liquids. Various sizes and configurations are available to satisfy wide applications. Our team equipped with both profession and experience in the field of plastic extrusion. We provide suggestions and service for equipment integration to help customers save more money and get higher profits.
Liquid Feeder
Categories : Dosing, Measuring & Mixing Equipment
Quantitative constantly speed for conveying liquid, emulsion and oil. Accuracy up to ±0.5% ~ 1%. Machine only contacts with the hose which can be used for corrosive liquids. Hoses are easy to replace and reduce contamination after cleaning. The industrial 4.0 model which is used RS485 MODBUS. Easy to connect the computer, man-machine interface, PLC and other connections. ※ Speed and the hose will affect the accuracy.
Large-flow Twin Screw Feeder
Categories : Dosing, Measuring & Mixing Equipment
Large-flow Twin Screw Feeder
Injection Molding Machine Plastic Auxiliary Solutions
Categories : Turnkey & Auxiliary Integration Solutions
YANN BANG offers a wide range of auxiliary equipment specificaly for injection molding mechines, like hopper dryers, dehumidifying dryers, chillers, PET crystallizers, vacuum loaders, mold temperature controllers, master-bacth feeders and auto dosing and mixing systems. Better company image Greater productivity Lower cost Better energy efficiency Less material waste and pollution during the conveying process Better working environment Less noise due to the separation of the blowers from the working place
High Pressure Liquid Injector-PSX
Categories : Machine-Specific Spare Parts
The PSX high-pressure liquid injector was developed by Sino-Alloy Machinery as an important accessory to their extruder line. The PSX high-pressure liquid injector is made up of a storage tank, proprietary precision plunger pump, and one-way valve type fluid injector. It can generate pressures as high as 50 kg/cm. This feeder can be connected to any feeding port of the extruder. The PSX high-pressure liquid injector is also capable of injecting high pressure gases or super-fluid liquids. Not only is it suitable for the injection of liquid and gaseous additives in rubber or plastics materials, but also for may plastic and rubber reactive processes or the injection of liquid ingredients in food and pharmaceutical. The PSX high-pressure liquid injector can also be supplied with heating and insulation devices, loss-in-weight metering devices, or flow controllers for precise measurements of the input quantity.
Gravimetric Auto Dosing & Mixing System (ADMG)
Categories : Dosing, Measuring & Mixing Equipment
COST SAVE: ADMG can measure powder resin, granule resin, master-batch, or additive precisely. EASY OPERATE: By entering the percentage of each batch and supply value to operate effectively, HMI automatically calculates all required values operate and monitor by single personnel or connect a PC through a modern to through a modern to maintain the system or solve problem. HMI is dynamic and versatile to provide the most efficient and economic operation. ACCURACY & CONSISTENCY: ADMG automatically measures the required amount accumulatively in order when you add extra resins or additives which will not affect the precision of dosing or mixing. ERROR REPORT: Error problems are recorded the time by day, month, and year for the maintenance. EASY CLEAN & SPACE SAVE: Stainless design and individual function units are easy to discharge and install.
Gravimetric Blenders - SGB
Categories : Dosing, Measuring & Mixing Equipment
• Evenly mixing of materials after accurately weighing, control accuracy strictly of ±0.1~±0.3%. • Auto calibration after each material weighting ensures accuracy. • Up to 100 recipes can be stored for later use. • Alarm log function. • All parts detachable for easy cleaning. • For SGB-600 and models below, machine mount model is the standard supply (equipped with magnetic base,manual discharge valve), optional pneumatic slide gate is available also. • For SGB-2000 and models above, floor stand is the standard supply (equipped with moveable floor stand, storage hopper and pneumatic slide gate), optional SBU suction box is available also. • Has the function of recycled material compensation (recycling hopper is standardly equipped with low level switch). Aberration coompensation can be automatically calculated based to the feeding amount of recycled materials. • Memory card can be optional selected to store ratio information for product quality control. • Hopper low level sensor can be optional selected to send alarm when material is insufficent. • Optional analog signals (0~10V) output function for screw automatic adjusting of extrusion molding machine. • RS485 communication is optional to realize the centralized monitoring of connecting with molding machine. • Floor stand, pneumatic slide gate, storage bin and suction box should be optionally purchased for floor mounting. (Applicable for SGB-600 and models below)
Gravimetric Doser SGD
Categories : Dosing, Measuring & Mixing Equipment
SGD gravimetric doser is suitable for continues precision dosing of masterbatch to the plastic process machine. The unit has a selection of four dosing screw sizes for different throughput needs. The unit can supports up to two sets of dosing screws for various material receipt. The lose-it-weight technology allows doser to measure and correct dosing to realize constant dosing precision. SGD syncronize dosing speed in extruder mode via analog 0~10V input from the extruder. Combination of Shini VL venturi loader realizes auto conveying of material to SGD at all time.
Single Screw Feeder-PSA
Categories : Dosing, Measuring & Mixing Equipment
The PSA series single-screw feeder was developed by Sino-Alloy Machinery as an important accessory to their extruder line. Its design is based on Sino-Alloy’s years of experience. The PSA single-screw feeder has a large feeding screw chamber for a smooth flow of the feeding material. Options include standard double-flight, single-flight, T-type, and spring type screws, which can be swapped easily and quickly to match the feeding material. The advantages of the intermeshed type of screw pairs are powerful displacement right-angle conveying, self-cleaning of the screws, high feed volume, and stable feeding. Sino-Alloy can also tailor the design of the feeder to match extruders from other manufacturers. Customers can also specify options such as premix, vibrate, preheat or cooling to suit production demands.
Feeder-Ruder Pellet Making Extruder
Categories : Rubber Mixing & Pre-Processing Equipment
This new model Feeder-Ruder Pellet Extruder usage for extruding and pellet producing after Plastic or Rubber compound mixing in the Dispersion Kneader and conveying to the hopper of this machine. Pellets making method with mold Hot Face Cutting and Water ring cutting two kind..
Feeder-Ruder Pellet Making Extruder
Categories : Rubber Mixing & Pre-Processing Equipment
This new model Feeder-Ruder Pellet Making Extruder usage for extruding and pellet making after Plastic or Rubber compound mixing in the Dispersion Kneader and conveying to the hopper of this machine. Pellets making method with mold Hot Face Cutting and Water ring cutting two kind.
Blow Molding Machine Plastic Auxiliary Solutions
Categories : Turnkey & Auxiliary Integration Solutions
For blow molding mechines, we can supply a wide variety of auxiliary equipment, e.g.: hopper dryers, dehumidifying dryers, chillers, PET crystallizers, vacuum loaders, mold temperature controllers, master-bacth feeders and auto dosing and mixing systems. Better company image Greater productivity Lower cost Better energy efficiency Less material waste and pollution during the conveying process Better working environment Less noise due to the separation of the blowers from the working place
Belt Type
Categories : Dosing, Measuring & Mixing Equipment
Loss-In-Weight Feeder is a precision feeding device designed specifically for handling granular or free-flowing powdered materials. Utilizing advanced technology, this feeder is capable of delivering maximum accuracy at minimal feed rates, meeting the precise ingredient requirements in different industries.
Knife-Cutting Bag Making Machine (GF-A812E-SV+C)
Categories : Cutting Machines
The GF-A812E-SV+C is a servo-driven knife-cutting bag making machine for bottom sealing bags. In the single-deck GF-A812E/SV configuration it makes 2 x 400 mm W bags or 1 x 800 mm W bags with a cutting width of 850 mm and a cutting length of 1200 mm, on film from 0.01 - 0.1 mm thick. The rear feeder is controlled by feeding sensors, sealing is a single sealing line with one sealing knife, and cutting is by a separate cutting knife. The machine is controlled through an HMI panel with a YASKAWA servo drive from Japan, and automatic stacking is standard. The same series extends to double-deck, triple-deck and 4-deck models — for example the GF-A824E/SV, GF-A836E/SV and GF-A848E/SV — for higher output from one footprint, with special designs available upon request. Options include a hole punch device, printing scanner and automatic punch unit. Type: knife-cutting bag making machine, bottom sealing bag Single-deck model GF-A812E/SV: 2 x 400 mm W or 1 x 800 mm W Cutting width: 850 mm; cutting length: 1200 mm Film thickness: 0.01 - 0.1 mm Rear feeder controlled by feeding sensors; 1 sealing knife, single sealing line; 1 cutting knife Control: HMI; servo drive YASKAWA / JAPAN; automatic stacking Multi-deck versions: double, triple and 4-deck models; options: hole punch device, printing scanner, auto punch unit
Anti-Leakage Vacuum-PSY
Categories : Valves & Manifolds
The PSY anti-overflow vacuum was developed by Sino-Alloy Machinery as an important accessory to their extruder line. Developed to prevent extruded material overflow from the vacuum vent during degassing and subsequent vacuum failure. The PSY anti-overflow vacuum is driven by a pair of vertical intermeshed screws to move overflow material back to the material barrel while degassing with the vacuum. Can also be installed on side feeders to prevent overflow.
Side Sealing Bag Making Machine Biodegradable Material(GF-S/SV Series)
Categories : Plastic Bag Making Machines
The GF-S/SV Series is a side sealing bag making machine configured for biodegradable material. It is the biodegradable-film version of JANDI'S GF-S/SV and SE/SV side sealers: folded or tubular film is sealed and cut along the side to make side-seal bags from PLA and PBAT based film.The GF-S/SV layout includes a rear feeder with gusset, fold, slitter and adhesive tape applicator functions, a servo drive, an HMI control panel, a printing scanner, a conveying belt and a collecting table. Options in the range include tension control, EPC edge guiding, a triangle folding device, punch hole and Mexican-hat punch devices, ultrasonic sealing, a perforating sealing knife, an envelope punching mould and an automatic stacking table. Cutting width, cutting length, film thickness range and production speed are confirmed at quotation.Type: side sealing bag making machine for biodegradable material, GF-S/SV SeriesMaterial: PLA and PBAT based biodegradable filmServo drive with HMI control panelRear feeder: gusset, fold, slitter, adhesive tape applicatorPrinting scanner, conveying belt and collecting tableOptions: tension control, EPC, triangle folding, punch hole, Mexican-hat punchOptions: ultrasonic sealing, perforating sealing knife, envelope punching mould, automatic stacking tableCutting width, length, film thickness and speed confirmed at quotation
Side Sealing Bag Making Machine(GF-S/SV Series)
Categories : Cutting Machines
The GF-S/SV series is JANDI'S range of servo-driven side sealing bag making machines, covering four cutting widths so that a converter can match the machine to its bag sizes. The GF-24SE/SV pairs with the GF-S600/SV at 600 mm cutting width, followed by the GF-32SE/SV and GF-S800/SV at 800 mm, the GF-40SE/SV and GF-S1000/SV at 1000 mm, and the GF-50SE/SV and GF-S1200/SV at 1200 mm. Cutting length is 800 mm across the series, on film from 0.01 - 0.1 mm.SE models run at Max. 200 Cycles/Min and S models at Max. 150 Cycles/Min. Every machine in the series carries a rear feeder with gusset, fold, slitter and adhesive tape applicator, HMI control, a YASKAWA/JAPAN servo drive, a SICK/GERMANY printing scanner, a conveying belt and a collecting table. Optional equipment includes tension control, EPC, a triangle folding device, punch hole and Mexican hat punch devices, ultrasonic sealing, a perforating sealing knife, an envelope punching mold and an automatic stacking table.Type: side sealing bag making machine series, servo driveCutting widths: 600 mm (GF-24SE/SV, GF-S600/SV), 800 mm (GF-32SE/SV, GF-S800/SV), 1000 mm (GF-40SE/SV, GF-S1000/SV), 1200 mm (GF-50SE/SV, GF-S1200/SV)Cutting length: 800 mm; film thickness 0.01 - 0.1 mmProduction: SE model Max. 200 Cycles/Min; S model Max. 150 Cycles/MinStandard: rear feeder with gusset / fold / slitter / adhesive tape applicator, HMI, servo YASKAWA/JAPAN, printing scanner SICK/GERMANY, conveying belt, collecting tableOptions: tension control, EPC, triangle folding, punch hole, Mexican hat punch, ultrasonic sealing, perforating knife, envelope punching mold, automatic stacking table
Spaghetti Type Recycling Machine(GSR Series)
Categories : Recycling Lines by Application
The GSR Series is JANDI'S water cooling, spaghetti type recycling machine for polyethylene and polypropylene film scrap. Film is fed by a spiral feeder into the extruder, and the melt is extruded through a spaghetti type die head into strands; the strands are cooled in a stainless steel water tank, dried by a blower and cut into pellets by a pull and cutting unit with a rotary cutter and fixed blade. A screen changer driven by an AC motor with reducer filters the melt ahead of the die.The series covers a range of extruder sizes and motor ratings so that capacity can be matched to the scrap volume of a film or bag plant; the figures for each model are listed per model in JANDI'S GSR specification table. Options include a conveyor with metal detector, crusher, screw conveyor, vacuum pump, pressure gauge, hydraulic screen changer, second extruder, vibrating screen and an air blower with storage tank. Details are available with quotation.Type: water cooling, spaghetti type recycling machine, GSR SeriesMaterial: HD/LD/LLDPE and PP film scrapSpiral feeder into the extruderScreen changer driven by AC motor with reducerSpaghetti type die head, stainless steel water tank and blowerPull and cutting unit with rotary cutter and fixed bladeOptions: conveyor with metal detector, crusher, screw conveyor, vacuum pump, hydraulic screen changer, second extruder, vibrating screenExtruder size and capacity per model, confirmed at quotation
Die Face Cutting Type Recycling Machine(GHR Series)
Categories : Recycling Lines by Application
The GHR series is a die face cutting type plastic film recycling machine for HD, LD and LLDPE and P.P. film scrap, producing pellets that can go back into the extruder. Scrap is fed into a stainless steel densifying tank with rotary cutters, then extruded through a hydraulic screen changer and cut at the die face; the pellets are dried in a stainless steel centrifuge unit and collected in a stainless steel storage unit. The series covers extruder sizes of 65 mm, 85 mm, 100 mm and 120 mm.Motors with inverter are 50 HP, 75 HP, 100 HP and 125 HP across the four sizes, for maximum capacities of 120 KG/HR, 200 KG/HR, 300 KG/HR and 400 KG/HR. Options include a conveyor with metal detector, crusher, screw conveyor, vacuum pump, pressure gauge, second extruder, film roll feeder and vibrating screen. JANDI'S notes that adding a crusher makes it easier to handle scrap of different sizes such as loose film and die-cut waste, gives a more even temperature in the densifying stage, and results in more stable feeding, more stable extrusion output and more uniform pellet sizes.Type: die face cutting type plastic film recycling machineMaterial: HD/LD/LLDPE & P.P.Models: GHR65E, GHR-85E, GHR-100E, GHR-120E; extruder 65 mm, 85 mm, 100 mm, 120 mmMotor with inverter: 50 HP, 75 HP, 100 HP, 125 HPMax. capacity: 120 KG/HR, 200 KG/HR, 300 KG/HR, 400 KG/HRDensifying tank with rotary cutters, hydraulic screen changer, centrifuge drying unit and storage unit in stainless steelOptions: conveyor with metal detector, crusher, screw conveyor, vacuum pump, 2nd extruder, film roll feeder, vibrating screen
Extrusion Molding Machine Plastic Auxiliary Solutions
Categories : Turnkey & Auxiliary Integration Solutions
We are capable of offerring a wide range of auxiliary equipment specificaly for extrusion molding mechines, like hopper dryers, dehumidifying dryers, chillers, PET crystallizers, vacuum loaders, mold temperature controllers, master-bacth feeders and auto dosing and mixing systems. Better company image Greater productivity Lower cost Better energy efficiency Less material waste and pollution during the conveying process Better working environment Less noise due to the separation of the blowers from the working place
Automatic Valve Forming and Double Head Sewing Machine
Categories : Paper Bag Making Machines
The machine includes the bag feeder unit, valve former, double head sewing machine and counting conveyor for processing the tube made from multi-wall PP paper bag making machine to form a bottom sewn ready bag.
TSCMX TVMC-855 High-Precision CNC Vertical Machining Center
Categories : CNC milling machine
Product Overview Engineered by SUN SERENE INTERNATIONAL (TSCMX - TAIWAN SMART CNC MACHINES), the TVMC-855 embodies over 20 years of Taiwanese machine tool craftsmanship and mechanical engineering expertise. Designed for high-speed, heavy-load, and precision batch production, the TVMC-855 combines structural rigidity with smart manufacturing readiness. With 100% Taiwan R&D and precision engineering paired with assembly in Thailand, TSCMX delivers an exceptional balance of mechanical reliability, tariff optimization, and rapid regional engineering support across ASEAN and global manufacturing supply chains. Key Engineering Features & Structural Rigidity Reinforced High-Rigidity Castings: Built on heavily ribbed castings and an ultra-wide base column design that effectively absorbs vibration during heavy-duty cutting, extending tool life and ensuring superior workpiece surface finishes. 6-Block Z-Axis Linear Guideway Design: Features low-friction, high-precision linear guideways across all axes, reinforced by six heavy-duty guide blocks on the Z-axis for uncompromised spindle head stability and torsional resistance. High-Speed Axis Dynamics: Achieves rapid traverse rates of $48\text{ m/min}$ on the X, Y, and Z axes, substantially minimizing non-cutting cycle times for mass-production environments. Powerful BT40 Spindle & Fast Tool Changing: Equipped with an $11\text{ kW}$ spindle motor ($8,000\text{ RPM}$) and a rapid 24-tool arm-type automatic tool changer (ATC), enabling milling, drilling, boring, reaming, and tapping in a single clamping setup. Strict JIS Accuracy Standards: Fully compliant with JIS B 6336-4:2000 precision standards, guaranteeing positioning accuracy of $0.008\text{ mm}$ and repeatability of $0.006\text{ mm}$. Smart Manufacturing & Turnkey Integration Next-Generation AI NC Code Generation: Seamlessly integrates next-gen AI drawing recognition to generate automated NC programs, dramatically reducing RFQ calculation cycles and lowering technical barriers for machine operators. Full Turnkey & Custom Engineering: Backed by 20+ years of closed-loop project delivery—from customized pneumatic/hydraulic clamping fixtures, coolant-through-spindle (CTS) systems, to 4th and 5th-axis rotary table integrations. Flexible CNC Controller Integration: Native support and deep integration with leading industrial CNC controllers, including Syntec, FANUC, and Mitsubishi. Target Applications & Industry Solutions Specially optimized for complex geometry and high-precision tolerances across mission-critical industries: Automotive & Motorcycle: Connecting rods, transmission shafts, sleeves, and engine components. Aerospace & Drone: High-strength structural brackets, motor mounts, and airframe hardware. Semiconductor & Electronics: Vacuum chamber brackets, precision fixtures, and heat-sink blocks. High-Spec Plumbing & Fluid Systems: Precision valves, manifold blocks, connectors, and fluid control bodies.
Rigid Sheet Extrusion Line
Categories : Cast Film, Sheet & Board Extrusion Lines
1. Extruder is driven by AC Inverter duty motor, with excellent efficiency and lowest power consumption. 2. Extruder hopper with low-level sensor work with auto-feeder will keep material in stable supply. 3. Hydraulic driven screen changer avoid any particle goes to melting pump & flat-die. 4. Melting pump with accurate rotation control, keeps the material flow stable. 5. Extruder & melting pump speed is working on pressure synchronized controlling system.
PP PE Bottle Washing Line with Modular Design
Categories : Recycling Lines by Application
Transform post-consumer plastic bottles and containers into clean,high-quality recycled flakes with a high-performance PP PE bottle washing line engineered for efficient plastic recycling.This complete system is designed to process contaminated polypropylene (PP) and polyethylene (PE) materials,including HDPE bottles,PP containers,detergent bottles,household packaging,and other rigid plastic waste. Combining automated sorting,size reduction,friction washing,hot or cold cleaning,separation,drying,and material handling,the pp pe plastic bottle washing line delivers a reliable and efficient solution for recycling plants seeking to improve material recovery,reduce operating costs,and produce consistent recycled feedstock. Product Overview The pp pe recycling line is a complete recycling system that converts collected plastic bottles and rigid containers into clean,dry,and uniform plastic flakes.The equipment configuration can be adapted to accommodate different feedstock conditions,contamination levels,capacity requirements,and final product specifications. The PP PE crushing and washing line is suitable for recycling plastics contaminated with: - Dirt,dust,and sand - Labels and paper - Adhesives and glue residue - Oil and grease - Food residue - Detergent and chemical residue - Organic contaminants - Other lightweight and heavy impurities After processing,the recycled flakes can be used as raw material for plastic extrusion,injection molding,blow molding,sheet production,pipe manufacturing,and other plastic processing applications. Main Processing Stages 1. Feeding and Pre-Sorting The recycling process begins with a conveyor or belt feeder that delivers the collected PP and PE bottles into the PP PE Plastic bottle recycling machine line at a controlled rate.Manual or automated pre-sorting can be incorporated to remove unsuitable materials,oversized items,metals,PVC,and other contaminants before washing. 2. Label and Cap Separation A label remover or sorting section separates loose labels,sleeves,caps,and other lightweight materials from the primary plastic stream.This stage helps improve the purity of the finished flakes and reduces the load on downstream washing equipment. 3. Crushing and Size Reduction A heavy-duty plastic crusher machine or plastic recycling granulator machine reduces bottles and containers into uniform flakes.The cutting chamber and blade configuration are designed for continuous operation and efficient processing of rigid PP and PE materials. Consistent flake size improves washing performance,material separation,drying efficiency,and the quality of the final recycled product. 4.Friction Washing The friction washer uses high-speed mechanical agitation to scrub the plastic flakes and remove dirt,labels,adhesive,and other surface contaminants.The washing action helps achieve a higher level of cleanliness while supporting continuous material flow. 5. Hot Washing or Intensive Cleaning For heavily contaminated materials,the pp pe recycle washing line may include a hot washing tank or heated cleaning stage.Hot washing is particularly effective for removing oil,grease,food residue,detergent residue,and stubborn adhesive contamination. The cleaning temperature,residence time,and chemical dosing can be configured according to the properties of the feedstock and the requirements of the final recycled flakes. 6. Float-Sink Separation A float-sink separation tank uses density differences to separate PP and PE materials from heavier contaminants such as stones,glass,metal,and other unwanted particles. This stage can also assist in separating certain incompatible plastics,depending on the material composition and process design. 7. Rinsing and Dewatering After washing,the flakes pass through rinsing equipment to remove residual cleaning agents and suspended contaminants.A high-speed dewatering machine then removes most of the surface water before thermal drying. 8. Thermal Drying The drying system uses controlled hot air to reduce residual moisture and prepare the flakes for storage,transportation,or further processing.Efficient moisture removal helps prevent processing problems during extrusion,injection molding,and other downstream applications. 9. Final Separation and Storage Air separators,magnetic separators,and other sorting devices may be used in PP PE bottles recycling machine to remove remaining labels,dust,metal particles,and lightweight impurities.The clean flakes are then conveyed to a storage silo,collection station,or packaging system. Key Features - Designed specifically for PP and PE bottle recycling - Complete continuous washing and recycling process - Suitable for post-consumer and post-industrial plastic waste - Efficient removal of dirt,labels,adhesives,oil,grease,and residue - Heavy-duty crusher designed for rigid plastic materials - Friction washing system for intensive mechanical cleaning - Optional hot washing for highly contaminated feedstock - Float-sink separation for improved material purity - High-efficiency dewatering and thermal drying - Configurable process layout and equipment combination - Automated material conveying between processing stages - Stainless steel components available for wet-contact sections - Designed for stable operation and simplified maintenance - Compatible with additional sorting,pelletizing,and extrusion equipment - Suitable for small,medium,and large-scale plastic recycling plants Advantages for Plastic Recycling Plants Improved Recycled Material Quality The multi-stage washing and separation process produces clean PP and PE flakes with reduced levels of dirt,labels,moisture,and other contaminants.Higher-quality flakes can increase the value of recycled material and expand its potential applications. Efficient Contamination Removal The combination of crushing,friction washing,hot washing,rinsing,density separation,and drying provides effective treatment for a wide range of contaminated plastic bottles and containers. Flexible System Configuration The pp pe washing line can be configured based on the type of plastic waste,contamination level,required output,available facility space,and final product requirements.Optional equipment can be added to support color sorting,advanced purification,or pellet production. Reduced Manual Handling Automated conveyors and integrated processing equipment reduce the need for manual material transfer.This improves production consistency and can help lower labor requirements. Reliable Continuous Operation The high quality pp pe washing line is engineered for continuous material flow,making it suitable for commercial recycling operations that require stable throughput and dependable performance. Support for Circular Plastic Manufacturing By converting used PP and PE bottles into reusable flakes,the pp pe plastic recycling line helps reduce plastic waste,conserve virgin resources,and support a more sustainable materials supply chain. Typical Applications The recycled PP and PE flakes produced by this PP PE plastic bottles cleaner can be used in: - Plastic extrusion - Injection molding - Blow molding - Recycled plastic pallets - Crates and containers - Pipes and fittings - Plastic sheets and boards - Automotive plastic components - Household products - Construction materials - Non-food packaging products - Plastic pellet production The final application depends on the cleanliness,color,polymer composition,moisture level,and processing requirements of the recycled flakes. Recommended Feedstock The PP PE bottles recycling machine is suitable for processing: - HDPE milk and detergent bottles - PP household containers - Plastic shampoo and cosmetic bottles - Rigid PP and PE packaging - Post-consumer plastic bottles - Industrial plastic containers - Mixed rigid plastic waste - Production scrap and rejected plastic products For mixed-material feedstock,an appropriate sorting system is recommended to remove PVC,PET,metal,rubber,and other incompatible materials before the washing process. Customization Options Each plastic recycling plant has different raw material and production requirements.The pp pe plastic recycling machinery can be customized with: - Manual or automated sorting systems - Different crusher capacities and screen sizes Hot washing units - Chemical dosing and water circulation systems - Additional rinsing tanks - High-efficiency dewatering equipment - Thermal drying systems - Air classification and label separation - Magnetic and metal separation - Color sorting technology - Flake storage silos - Automatic weighing and packaging systems - Water filtration and recycling equipment - PP PE pelletizing lines for further processing Conclusion The high-performance Polypropylene Polyethylene washer provides a complete and dependable solution for plastic recycling plants processing contaminated PP and PE bottles and rigid containers.Through efficient size reduction,intensive washing,density separation,drying,and impurity removal,the Polypropylene Polyethylene washer produces clean and reusable recycled flakes for a wide range of manufacturing applications. With a modular design,flexible configuration,and focus on reliable continuous operation,this pp pe plastic recycling plant is an ideal choice for businesses seeking to increase plastic recovery,improve recycled material quality,and build an efficient,sustainable plastic recycling operation. PP PE Bottle Washing Line with Modular Design Flexible Configuration Compatibility Automation:https://www.petrecyclingmachinery.com/PP-PE-Bottle-Washing-Line-with-Modular-Design-Flexible-Configuration-Compatibility-Automation-pd585697648.html Plastic Recycling Machines & Solutions - Haorui Machinery:https://www.petrecyclingmachinery.com/products.html PET Bottle Recycling Machine & Plastic Crusher - Haorui Machinery:https://www.petrecyclingmachinery.com/
PRECISION HYDRAULIC AUTOMATIC DIE-CUTTING MACHINE/4COLUMU TYPE CSS-603
Categories : Cutting Machines
Advanced & durable hydraulic circuit and steady electronic control system circuits adopted in the hydraulic system enable to achieve high operating performance. 4 steel posts design instead of guide-ways for punching movement and equipping linear guide-way for the front & rear feeders. The unit performs precisely, stably, quietly, nimble and powerful. lt'sconvenient even for the use at the upstairs of a factory. Cutting depth can be precisely set up to a tolerance of 0.008 mm. Through the use of the longwearing special designed steel plate to replace conventional cutting board, can prolong lift of cutter and obtain better cutting quality and efficiency Processed item may be full or half cut-off. ltems with adhesive may be used as well Products are free from rough edges. The machine is equipped with a protecting device to ensure safety of people and the machine. Automatic cooling system and full-auto cutting device are available for additionally purchase and fitting. Designed in high-precision construction, this machine can be used to perform full-cut and half-cut fabrication tasks. Up/down punching travel uses four high-rigidity guide poles, with linear rail designed for the feeding mechanism. Two-step pressure control to achieve flexible and lower noise operation. It is suitable for multi-level factory buildings. Automatic cutter adjusting mechanism can perform automatic adjustment according to the desired setting, providing 0.01mm accuracy (0.001mm optional). High-precision german steel plate is used to achieve higher durability and wear free operation. This machine uses advanced and durable hydraulic system and electronic control circuits. The machine is equipped with protection device to ensure the safety of the operator and the machine. (with CE optional)
MGF Gravimetric Feeders
Categories : Dosing, Measuring & Mixing Equipment
Robust hardware, integrated with industry-leading software control to achieve repeatable consistent dosing accuracy. Unique twin load cell technology Dosing accuracy ± 0.2% on 1% setting Feeder ideal for all molding and extrusion processes
FGS-SM Gravimetric Screw Feeder
Categories : Dosing, Measuring & Mixing Equipment
FGS series gravimetric screw dosers enable auto-proportional mixing of virgin materials, regrinds, masterbatch, or additives. Servo motor with fixed screw provides outputs of 0.2~38KG/HR. Configurable as dual-station systems.
