Fully Automatic High Speed 2 Lines T-shirt Bag Making Machine-ST-99

Classification : T-shirt Bag Making Machines
Country: Taiwan
Phone: 886-2-86782865
Fax: 886-2-86782869
Contact Person: Yarzar
Video Inquiry Now
  • Computer control over the entire process
  • From film roll to final pruduct, one process flow
  • Automatically stop when running out of film / film feeding blocks or jam
MODEL ST - 99
Production Size Length : 350 ~ 650 mm
Width : 160 ~ 365 mm
Thickness : 8 ~ 50 um
Production Speed
180 ~ 300  pcs / min / line
Film Roll Size Ø 900 x 365 mm
Power 220 V, 3 Phases,  50 / 60 HZ, 15 KVA
Heat 4.5 KW
Dimension L : 6750 mm W : 1550 mm H : 1750 mm
Air Compressor 10 HP ( not included )
