From film roll to final pruduct, one process flow
Automatically stop when running out of film / film feeding blocks or jam
MODEL | SCB-1100-L4 |
---|---|
Bag Length | 200 - 900 mm |
Bag Width | 100 - 420 mm |
Film Thickness | 0.008 - 0.035 mm |
Production Speed | 60 - 120 pcs / min / line |
Upload Film Roll Siza | Ø750 x 465 mm |
Power | 220V,3Phases,50/60HZ,10KVA |
Heater | 6KW |
Dimension L x W x H | 6550 x 1760 x 1840mm |
Packing L x W x H |
unwinder:1090x1670x1800mm machine:2250x1910x1890mm punch:2670x1760x1590mm |
Required Air Compressor | 5HP (not included ) |
Weight | 2600kg (net) / 3000kg (gross) |
MODEL
SCB-1100-L6
Bag Length
200 - 650 mm
Bag Width
100 - 310 mm
Film Thickness
0.008 - 0.035 mm
Production Speed
60 - 120 pcs / min / line
Upload Film Roll Siza
Ø750 x 310 mm
Power
220V,3Phases,50/60HZ,10KVA
Heater
6KW
Dimension L x W x H
6550 x 1760 x 1840mm
Packing L x W x H
unwinder:1090x1670x1800mm
machine:2250x1910x1890mm
punch:2670x1760x1590mm
Required Air Compressor
5HP (not included )
Weight
3700kg (net) / 4000kg (gross)
MODEL
SCB-1100-L8
Bag Length
200 - 650 mm
Bag Width
100 - 230 mm
Film Thickness
0.008 - 0.035 mm
Production Speed
60 - 120 pcs / min / line
Upload Film Roll Siza
Ø750 x 230 mm
Power
220V,3Phases,50/60HZ,10KVA
Heater
6KW
Dimension L x W x H
6550 x 1760 x 1840mm
Packing L x W x H
unwinder:1090x1670x1800mm
machine:2250x1910x1890mm
punch:2670x1760x1590mm
Required Air Compressor
5HP (not included)
Weight
3800kg (net) / 4100kg (gross)
