Classification : T-shirt Bag on Roll Making Machine
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final pruduct, one process flow
- Automatic film feeding, cordination free from tension adjustment
- Oscillation film feeding system for stability and high out put
- Automatically stop when running out of film / film feeding blocks or jam
- Automatically core changing system
- Punch system on magnetic roller
| MODEL | STBCR-40+OS |
| Production Size | Length : 350 mm (min) |
| Width : 180 ~330 mm | |
| Thickness : 6 ~ 35 um | |
| Roll size : Ø 180 mm (max) | |
| Core size : Ø 25 ~ 75 mm, thickness 3 mm (min) | |
| Production Speed | 200 pcs / min / line |
| Film Roll Size | Ø 900 x 330 mm |
| Power | 220 V, 3 Phases, 50 / 60 HZ, 25 KVA |
| Heater | 7KW |
| Dimension | L : 8000 mm W : 2400 mm H : 1950 mm |
| Air Compressor | 10 HP ( not included ) |
