Servo Driven Beam Robots - Bomarc series

Classification : Injection Robot

ALFA INDUSTRIAL GROUP

ALFA INDUSTRIAL GROUP
Country: Taiwan
Phone: 886-2-22053863 / 86-769-83120300
Fax: 886-2-22053853 / 86-769-88602226
Contact Person: Mr. Arno Chang
B□□□□ID/IS/WD/WS /A/G /S2
Model: 700/900/1000/1200
W : double cut
I : single cut
D: arms (finished arm + material arm)
S : one arm (finished arm)
S2: horizontal, the upper arm of the finished arm is servo driven

General specifications


power supply
Power Source



Power supply (KVA)
Power Source



working pressure
Working Pressure



Maximum allowable air pressure
Max.Allowed Pressure



Drive mode
Drive System



Side pose
Swivel



1ΦAC220V±20V
50/60HZ


1.0


5Kgf/cm 2
0.49Mpa



8Kgf/cm 2
0.8Mpa



Y: AC Servo Motor
X, Z: Pneumatic Cylinder



90° Fixed
Pneumatic



Main specifications

model


B700
ID/IS/WD/WS(S2)



B900
ID/IS/WD/WS(S2)



B1000
WD/WS (S2)



B1200
WD/WS (S2)


Applicable molding machine (ton)

50-200

200-350

350-450

450-550

Horizontal travel (mm)

1300 (1500)

1700

1800 (2000)

1800 (2000)

Horizontal drive

AC servo motor drive

AC servo motor drive

AC servo motor drive

AC servo motor drive

Drawing stroke (mm)

P: 150 R: 100

P: 300 R: 100

P:400 R:150

P:400 R:150

Up and down stroke (mm)

700 (900)

900

1000 (1200)

1200

Maximum load (Kg)

5

5

10

10

Take time (sec)

2.4(1.2)

2.9 (1.5)

3.1(2)

3.5 (2.4)

Full lap time (sec)

8(4.5)

8.8(5)

9.3(6)

10.5 (7.5)

Air consumption (NI/cycle)

20(9)

25(11)

30(11)

36(12)

Net weight (Kg)

190-240

235-270

280-340

295-345

* Due to continuous improvement of the model, the appearance and specifications are subject to change without notice.
* S2: refers to the horizontal line, the upper and lower two-axis servo models of the finished arm
