PET Stretch Blow Molding Machine - Economy Affordable New Choice (EX Series)

Classification : PET BLOW MOLDING MACHINE
Country: Taiwan
Phone: 886-4-23345536/ 86-595-88169879
Fax: 886-4-23345539/ 86-595-88165687
Contact Person: Claire
Inquiry Now
●  Blower power consumption for 1000 bottles: 2Wh.
●  Air Compressor power consumption for 1000 bottles: 6 kWh compact space.
●  Screw driven controlled by servo motor providing fast and smooth motion.
●  Single lamp bilateral centralized heating, easy controlled within 3°C and energy heating.
●  Low-pressure air compressor will NOT be required due to high-pressure recovery system.
●  High efficient air recovery system up to 45%.
Model Unit EX02MC EX02MC-SH EX04MC EX04MC-SH
Cavity no. cavity 2 2 4 4
Theoretical Output BPH 2000 2000 4000 4000
Preform Holder pcs 62 62
Heating pitch mm 62 62 62 62
Cavity pitch mm 114.3 114.3 114.3 114.3
Bottle volume Max. 1.5Ltr. 1.5Ltr. 1.5Ltr. 1.5Ltr.
Preform neck Max. (mm) 38 38 38 38
Preform height Max. (mm) 150 150 150 150
Bottle diameter Max. (mm) 105 105 105 105
Bottle height Max. (mm) 320 320 320 320
Oven no. box*channel 1*2 1*2 1*4 1*4
Heating power kW 19 38 38 76
Installed power kW 24 48 48 96
Machine size cm 230*220*350 230*220*350 430*410*350 430*410*350
Machine wt. kg 2500 2500 5500 5500
Origin Taiwan
China

  • Adopt the touch screen control system with 64K color and friendly PLC operation.
  • Exclusively designed machine construction makes it convenient to combine the blow molding machine with conveyor system.
  • The preforms are automatically arranged in order for feeding system at a single way and the dividing carrier is driven by a servo motor; this way will avoid preforms jamming, causing machine down or preforms waste.
  • Adopt a servo control screw driving system; it is rapid, stable, clean and environmentally friendly.
  • The preforms are fed into the heating system in a matrix mode and uniform heated by single-lamp with double-sided heating.
  • Employ a single-lamp with double-side heating design and will save about 50% heating consumption compared with competitor method.
  • With the temperature feedback function, temperature in the heating oven is automatically controlled by adjustment of infrared lamps to reduce prefrom crystallization problems.
  • Specially designed heating box upgrade convenience of maintenance in changing infrared lamp and cooling ramp.
  • The clamping mechanism is driven by a combination of servo motor and cam; this results in accurate and stable motion, low noise and minimal pollution.
  • Utilizes the air recovery system and efficiency up to 50% so that the low-pressure air compressor will not be required. This will save equipment investment costs and energy consumption by up to 15%.
  • The bottle discharge position is equipped with a connecting device that connects to the air conveyor, which permits the formed bottles to be directly fed to the filling system.
