JS 237APR / JS 2310APR2 PET Heavy Duty Strapping Band Making Machine
Categories : Tape Extrusion Machines
Extruding output range: 40 - 100 kgs/hr or 80 - 220 kgs/hr. Band width: 9.5 -19mm. High precision band width +/- 0.5mm. Entire machine employs direct drive for low noise running. Gears are hardened and precision ground for quiet running performance. SACMI screw is nitrogen treated, precision ground, and stress relieved. SACMI barrel is nitrogen treated, precision ground, and stress relieved. #304 stainless steel cooling water tank. Separate adjustment for winding torque and running speed ensures uniformity of band. Stretching unit is all-gear driven with oil bath lubrication for stability, quiet running and long service life. WINDING UNIT The winding unit is driven by a DC torque motor, featuring torque adjustment. The buzzer sounds when the preset length of band is reached. Changing the gears conveniently changes the winding width. Aluminum winding rollers. Choice of 200 or 400mm core bobbin. PRE-HEAT STRETCHING UNIT The machine uses electric heating to quickly achieve high temperature. The four stretching rollers are individually driven, and heated for efficient stretching. Stretching speed is controlled by a frequency inverter for maximum stability. EMBOSSING ROLLER The embossing rollers are manufactured from SKD11 material, vacuum heat treated for superior hardness and maximum wear resistance. Embossing depth is pneumatically adjusted with indication reader for accurate reading. Separate motor drive. MAIN CONTROL PANEL The temperature for the barrel, screw, and die are separately displayed on the main control panel. Temperature can be preset. JS 2310APR2 Hydraulic screen change. JS 2310APR2 2 layer straightening operation extends heating time, ensuring the stability of bands and superior tensile strength. Hot air circulation provides for a more efficient heating solution. Equipped with a water cooling tank for upgrading cooling and stiffening performance. Outstanding dehumidifying performance ensures constant band quality. DEHUMIDIFYING DRYER The dehumidifying dryer lowers the moisture content below 0.2% to achieve the utmost performance from production materials. The dryer prevents such problems as cracking, streaking, bubbles, flow marks, poor transparency, etc., which are all caused by incompletely dry resin.
Sun Roof Related Parts
Categories : Injection Molded Products
This product is a sunroof front pillar, specifically designed for automotive sunroof systems to provide structural support and fixation, ensuring stable sunroof operation and maintaining vehicle rigidity. It is manufactured using high-strength PP+GF (Glass Fiber Reinforced Polypropylene) material, offering lightweight properties, impact resistance, heat resistance, and low deformation rate, effectively enhancing vehicle safety and durability. Produced with a 1600-ton large injection molding machine, this product guarantees high precision, consistency, and durability, making it suitable for various sunroof systems, including panoramic sunroofs, electric sunroofs, and manual sunroofs. Additionally, its design features excellent drainage performance, efficiently preventing water accumulation, leakage, and flooding issues, ensuring long-term stable operation.
Stepper-Controlled Proportional Valve 0-65L/min
Categories : Separators
Product Serial: FC-20+PM-20 Proportional Flow Control Valve consists of PM series driver and FC series proportional flow valve. With an input signal either through analogue or digital, the needle inside the proportional valve moves proportionally to the signal. This series is able to control the flow rate of air and liquid with high resolution, high accuracy, and high repeatability. It is developed for industries that require a high degree of adjustment in flow rate. Series PM driver provides series FC valve with the required power and control signal (step and direction). It controls the step of a bipolar stepper motor with an analogue signal (0-10 VDC/4-20mA/RS485 Modbus).
Proofing Machines FCM-1300
Categories : Slitters and Rewinders
Applications of FCM-1300 Proofing and sampling for engravers & packaging printers Functions of FCM-1300 Check cylinder engraving quality including the accuracy of text, colors and ink standards. Production press simulation for samples with different colors offers variety for customers. Benefits of FCM-1300 One man operation. 10 minute proofing. Reduces ink and material use. Maximizes production press time. Use production inks and materials. Features of FCM-1300 1. Machanical position on printing roller In combination with inductive proximity switch and mechanical headstock can make sure the printing roller will return to exact position before every proofing. 2. High solution cameras and video registration system With a high solution camera and an electronically generated dual cross on the screen which 16 times magnifies the arrow on every cylinder can eliminate parallax error. 3. Adjustable doctor blade device Consists of 2 doctor blade to intense the hardness. Adjustable angles and pressure accommodates variable patterns of the cylinder. 4. Shaft-less air chuck Allows easy and safe loading of a cylinder and wash-off by one operator. It can be suttle adjusted to accommodate different width of the cylinder. 5. Adjustable cylinder deck Easy and safe operation for loading the cylinder by pneumatically adjusting the deck upward and downward. 6. Superduper printing roller (1)Smooth, rustproof, and heavy-duty printing roller through chromium-electroplated and grinding process. (2)Bouncy compressible blanket, closely dovetailed with printing roller, can easily be replaced when it is blot and spoiled. (3)The proofing length is up to 2500mm. Depending on the size of cylinders, it can print at least 2 copies of samples in every proofing. 7. Powerful vector motor The printing roller is driven by an powerful 7.5 HP vector motor. 8. Adjustable proofing speed Accommodating different material and ink quality, the proofing speed can be adjusted from 20 to 90 m/min. 9. Linear guide way All of the sliders applied to air chuck and cylinder adopt linear guide ways. With height position exactitude, the device will not facilely glide on linear movement.
PPV Proportional Pinch Valve
Categories : Separators
Product Serial: PPV Pinch valve works in a way to open or to close a fluid path in a flexible tube by squeezing or pinching the tube. With a proportional pinch valve, the shaft that pinches the tube is driven by a stepper motor, thus that the extent of pinching can be adjusted, which indirectly controls the fluid flow rate inside the tube. The advantage of using a pinch valve is that it has no contact with the fluid, making it an ideal option for biotechnology processing, food industry, dosing system, blood process/analytical, CIP and SIP process, and biopharmaceutical equipment. Our PPV series pinch valve is driven by the PM series driver that accept either analogue ( 0-10V or 4-20mA) or digital RS485 modbus signal. What is a Proportional Pinch Valve? A Proportional Pinch Valve is a type of pinch valve that combines the characteristic and features of a pinch valve and a linear stepper motor. It is a great way to control fluid flow or fluid pressure in applications that emphasize sterile, clean, non-contact, avoid cross-contamination environment, such as Biotechnology Chemical Processing Dispensing, Filling, & Mixing Process Equipment Bioreactors Medical Devices Pharmaceuticals Life Sciences Food Processing In this article, we will start by introducing what type of proportional pinch valve KaoLu could offer, followed by the working principle, and when should you use a proportional pinch valve, and then conclude with what you should consider before making a decision on which valve to purchase. What type of Proportional Pinch Valve does KaoLu offer? KaoLu offers mainly two types of proportional pinch valve – miniature and high torque version. Miniature version: please click on photo to product brochure ,or visit https://www.genndih.com/pinch-valve/proportional-pinch-valve.html Three versions are now available: PPV-04, for tube outer diameter (O.D.) 3.5 – 4.5 mm (~0.125” to 0.188”) PPV-06, for tube O.D. 5.5 – 7 mm (~ 0.25” ) PPV-08, for tube O.D. 7 – 9 m (0.375”) The tube O.D. is flexible because we are using flexible plastic tube, and as long as the tube can fit into the insertion slot, it will be functional. The higher torque version is suitable for soft and more rigid tubing, up to durometer of 75 shore A. Please click on photo for product brochures, or visit https://www.genndih.com/pinch-valve/proportional-pinch-valve.html It is available to up 5 different sizes PPV-930-64 – tube O.D. 6 – 7 mm (~ 0.25”) PPV-930-95 – tube O.D. 9 – 10 mm (~0.375”) PPV-930-127 – tube O.D. 12 – 13.4 mm (~0.5”) PPV-930-191 – tube O.D. 18.6 – 19.6 mm(~0.75”) PPV-930-254 – tube O.D. 24.8 – 25.8 mm (~ 1”) All our proportional pinch valve can be controlled by either analogue (0-10V or 4-20mA) or digital signal. There is also an option for encoder. For the correct selection of product, please contact our product consultant. We also provides a video demo on how proportional pinch valve function, please visit and subscribe for our latest videos. https://www.youtube.com/watch?v=5z31SR9wqgk What is the Working Principle of a Proportional Pinch Valve? A proportional pinch valve combines the features and advantage of a pinch valve and a linear stepper motor. Let’s firstly introduce you the concept of these two items. Pinch Valve A pinch valve works in a way by pinching or squeezing a flexible plastic tube through a shaft that can be controlled by solenoid electromagnetic principle, by pneumatic pressure, or by a linear stepper motor. Pinch valve is especially useful in applications that does not allow valve to be in contact with the fluid inside the tube, such as chemical reagents, food, corrosive fluid…etc. A traditional pinch valve only provides full open or full closure function, and the disadvantage is that there is a flow rate drop when the tube is inserted into the pinch valve, and there is no way to control fluid flow rate. Linear Stepper Motor A linear stepper motor is a type of actuator that used the characteristic of a stepper motor to achieve linear motion. The degree in which one can control a step distance and torque is greatly dependent on the control system and the stepper motor quality and characteristics. A stepper motor is commonly used when one requires high resolution, high repeatability, and high torque. Pinch Valve + Linear Stepper Motor = Proportional Pinch Valve The combination of both provides an excellent solution for application that requires an automation on process line that requires sanitary environment and applications that require cleanliness and sterility, as well as highly accurate incremental flow or pressure regulation. This eliminating the need for multiple-valve, high-maintenance assemblies, and this single valve offers a compact, efficient solution. When should I use a Proportional Pinch Valve? KaoLu is expert in pressure and flow regulation. Please refer to the graph below: Pressure Regulation: The left had side is the control of inline pressure with a traditional on/off pinch valve. The right hand side shows the pressure control with a proportional pinch valve. In a process line that does not allow fluid to be contaminated, one could consider a proportional pinch valve to adjust the inline pressure by controlled the opening of the tube via a proportional pinch valve. With a fine step control, the pressure could be adjusted in a high resolution manner. Flow Regulation: The graph shows that the inline fluid flow rate could be regulated by a proportional pinch valve. The curve could be shift leftward with either a higher resolution stepper motor control or by adjusting zero offset of the pinch valve. With a proportional pinch valve, one can easily control (non-contacting method) the inline fluid pressure and flow rate, this offers a great advantage to many industries. What should you consider when purchasing a Proportional Pinch Valve? 1. Tube: outer diameter, material, shore A, inner tube pressure 2. Performance: resolution, repeatability, can achieve desired accurate flow or pressure control 3. Control: analogue or digital control We called it TPC. It is important to understand the characteristics of the tube you are using and the operating pressure. Sometimes, a suitable tube may not work if you have a high inner tube pressure which the pinch valve could not squeeze or pinch at all. Secondly, the performance of the proportional pinch valve should be taken into account when choosing which brand of proportional pinch valve is suitable for you. With KaoLu’s proportional pinch valve, we are able to achieve up to 40000 steps per revolution and the velocity in which the pinch shaft moves to squeeze and the torque of the motor could be calibrated easily by our customers to suit different requirements. The third important factor is control method. With our digital control method, it is possible to operate the valve half a mile away from the valve itself. We also provide RS485 holding register where the user could adjust zero offset and other parameters to fit customized solution. Please visit our product website for further information. https://www.genndih.com/pinch-valve/proportional-pinch-valve.html and remember to visit our youtube channel and subscribe for latest video updates: https://www.youtube.com/channel/UCjQ9bjuSOT_csnVA9if4_EQ/videos
Pressed Powder Cosmetic Injection Mold
Categories : Injection Molds
Exterior make up case for famous brand e.g. SHISEIDO, ANNA SUI, PAUL & JOE, etc… Cosmetic box finished in mirror polish, plating, texture, in-mold labeling & vacuum plating. Provide high precision quality product with sophisticated appearance to showing high texture to customer.
WPP-A Contactless Magnetostrictive Linear Position Transducer(Analog Output)
Categories : Indicators and Sensors
Contactless linear position transducer with HYPERWAVE magnetostrictive technology. The absence of electrical contact on the cursor eliminates all wear and guarantees almost unlimited life. High performance in terms of environmental IP protection and EMC immunity. High accuracy of the mesurement with reference to the non linearity, repeatability and hysteresis. High resistance to vibrations, mechanical shocks for use in a harsh industrial environment.
85-150 ton injection molding machine product
Categories : Injection Molded Products
This 85-150 ton injection molding machine is designed for high-precision plastic product manufacturing, including automotive components, electronic parts, appliance housings, medical devices, and consumer goods. Equipped with a high-efficiency servo-driven system, it ensures stable injection pressure and precise control, delivering superior molding quality. With a high-rigidity clamping structure and an optimized hydraulic system, this machine offers durability and operational efficiency. It supports various plastic materials (PP, PE, ABS, PC, PA, etc.) and can be customized with multi-stage injection units and robotic interfaces for full automation, reducing labor costs and increasing productivity. Ideal for OEM manufacturers, plastic molding factories, and precision molding industries, this model meets modern production demands with efficiency and precision.
Stepper-Controlled Proportional Valve 0-1200L/min
Categories : Separators
Product Serial: FC-1000+PM-1000 Proportional Flow Control Valve consists of PM series driver and FC series proportional flow valve. With an input signal either through analogue or digital, the needle inside the proportional valve moves proportionally to the signal. This series is able to control the flow rate of air and liquid with high resolution, high accuracy, and high repeatability. It is developed for industries that require a high degree of adjustment in flow rate. Series PM driver provides series FC valve with the required power and control signal (step and direction). It controls the step of a bipolar stepper motor with an analogue signal (0-10 VDC/4-20mA/RS485 Modbus).
MEMS Gas Mass Flow Meter 0-1000L/min
Categories : Separators
KMF1000 series digital gas mass flow meter is made of micro- electromechanical system (MEMS) flow sensing chip, suitable for a variety of purposes of clean, relatively dry nature of the small flow gas measurement and process control, unique packaging technology makes the product to meet the different ranges of flow measurement, to ensure high sensitivity, high reliability, high stability and low cost. It is based on a MEMS flow sensing unit and a high precision digital processing and calibration circuit (MCU). The integrated Δ-Σ A/D converter and the logic circuit with internal calibration function and MCU processor together ensure the real-time effective acquisition of the sensing signal, to obtain the accurate flow signal, and the corresponding compensation algorithm processing in the internal, so there is no need to do any external calibration and compensation to ensure high-precision.
Single-Valve Dynamic Pressure Controller
Categories : Indicators and Sensors
Product Serial: QKL-UHR/QKL-B1HF
JS 284S/3V PP Straw Making Machine
Categories : Extrusion Lines For Pipes and Profiles
The gears are precision ground and hardened to ensure smooth and quiet operation. The high precision bearings provide and extremely smooth and long lasting running performance. The screw, manufactured from Aluminum Chromolybdenum alloy steel(SACMI), is stress relieved, precision ground and nitride treated for a long service life. The barrel, manufactured from Aluminum Chromolybdenum alloy steel(SACMI), is stress relieved precision ground and nitride treated for a long service life. The stainless steel (S410) die undergoes nitride hardening treatment for a long service life. The water tank is constructed of stainless steel # 304 The water stirage tank is power adjusted transversely and manually adjusted vertically to ensure convenient take-up and die-change. The easy to change, two-die system provides a straw diameter range from 3.8mm to 8mm with easy adjustment of thickness. High production rates for JS 284. 800-1200 pcs/min for 120mm sharp end straws. 300-500 pcs/min for 210mm straight straws. Variable straw length, 100mm-300mm, can be easily adjusted when the machine is running. The belt type take-up unit ensures and even stabilizing speed and prevents straw slippage during take-up operations. The toothed belt transmission incorporated with a DC motor ensures great stability for precision cutting and straw length accuracy. The cutting unit can produce both sharp end and straight straws.
