- Vertical mold clamping and injection, small footprint and high degree of precision. This machine is ideal for injection of medium and small products with inclusions.
- Dual-cylinder injection system offers high injecting pressure for fast operation, making this injection machine your best choice for production of thin items.
- Direct-pressure mold clamp allows even injection force, and the relatively low pressure means maximum precision and an incredibly smooth cycle of operation.
- Choose a platen or a rotary plate in accordance with the type of products to be injected, in order to achieve the best possible in feed and injection effects.
- This machine offers a wide range of programmable functions including automatic inclusion, extraction and fully-automatic production.
- There are also many other control systems that facilitate flexible production and keep costs low while maximizing precision.
Machine Type |
Unit |
K2S(D) |
KT-200-D(DM) |
KT-300-D(DM) |
KT-400-D(DM) |
KT-500-D(DM) |
KT-600-D(DM) |
KT-700-D(DM) |
KT-800-D(DM) |
KT-900-D(DM) |
||||||||||||||||||||||
Screw Diameter |
mm |
20 |
25 |
20 |
25 |
30 |
25 |
30 |
35 |
30 |
35 |
40 |
35 |
40 |
45 |
50 |
35 |
40 |
45 |
50 |
40 |
45 |
50 |
55 |
45 |
50 |
55 |
60 |
60 |
65 |
70 |
|
Injection Pressure |
kg/cm2 |
1715 |
1098 |
2730 |
1747 |
1213 |
2509 |
1742 |
1280 |
2170 |
1594 |
1220 |
2171 |
1663 |
1314 |
1064 |
2577 |
1973 |
1559 |
1263 |
2695 |
2129 |
1724 |
1425 |
3318 |
2688 |
2221 |
1866 |
1866 |
1590 |
1371 |
|
Theoretical Shot Volume |
cm3 |
31 |
49 |
31 |
49 |
71 |
59 |
85 |
115 |
99 |
135 |
176 |
135 |
176 |
223 |
275 |
173 |
226 |
286 |
353 |
276 |
349 |
432 |
522 |
381 |
471 |
570 |
678 |
678 |
796 |
923 |
|
Max. Shot Weight(PS) |
g |
29 |
45 |
29 |
45 |
64 |
54 |
77 |
105 |
90 |
135 |
160 |
123 |
160 |
203 |
250 |
158 |
206 |
261 |
321 |
248 |
314 |
388 |
469 |
343 |
424 |
513 |
610 |
617 |
724 |
840 |
|
oz |
1 |
1.5 |
1 |
1.6 |
2.3 |
1.9 |
2.7 |
3.7 |
3.2 |
4.3 |
5.7 |
4.3 |
5.7 |
7.2 |
8.9 |
5.6 |
7.3 |
9.3 |
11.3 |
8.8 |
11.2 |
13.8 |
16.7 |
12.2 |
15.1 |
18.3 |
22 |
22 |
25 |
30 |
||
Injection Rate |
cm3/sec |
20 |
30 |
22 |
35 |
50 |
36 |
52 |
71 |
51 |
69 |
90 |
82 |
107 |
135 |
167 |
87 |
114 |
144 |
177 |
102 |
129.3 |
159.6 |
193 |
123.6 |
148.3 |
178 |
212.5 |
247 |
291 |
336 |
|
Screw Stroke |
mm |
100 |
100 |
120 |
140 |
140 |
180 |
220 |
240 |
240 |
||||||||||||||||||||||
Screw Speed Max. |
rpm |
0-215 |
0-205 |
0-190 |
0-175 |
0-200 |
0-180 |
0-220 |
0-160 |
0-140 |
||||||||||||||||||||||
Nozzle Contact Force |
tons |
- |
2.0 |
2.4 |
2.6 |
2.9 |
3.3 |
4.2 |
6 |
8.7 |
||||||||||||||||||||||
Nozzle Retraction Stroke |
mm |
- |
140 |
180 |
200 |
220 |
300 |
300 |
320 |
340 |
||||||||||||||||||||||
Number of Temperature Control |
- |
2 |
3 |
3 |
3 |
4 |
5 |
5 |
5 |
5 |
||||||||||||||||||||||
Material Hopper Capacity |
| |
15 |
20 |
20 |
30 |
30 |
30 |
30 |
30 |
30 |
Machine Type |
Unit |
K2S(D) |
KT-200-D(DM) |
KT-300-D(DM) |
KT-400-D(DM) |
KT-500-D(DM) |
KT-600-D(DM) |
KT-700-D(DM) |
KT-800-D(DM) |
KT-900-D(DM) |
Clamping Force |
tons |
15 |
30 |
45 |
55 |
85 |
120 |
160 |
200 |
250 |
Opening Force |
tons |
7 |
6.5 |
8.3 |
13.5 |
10.5 |
15 |
20 |
26 |
28 |
Platen Size |
mm |
430x250 |
520x370 |
580x430 |
650x490 |
740x500 |
840x620 |
950x700 |
1070x810 |
1200x920 |
Distance Between Tie Bare |
mm |
250 |
355x205 |
400x250 |
500x340 |
560x320 |
620x400 |
750x500 |
870x610 |
920x640 |
Min. Mold Height |
mm |
100/40 |
160/100 |
210/150 |
260/200 |
250/200 |
250/200 |
250 |
300 |
300 |
Opening Stroke |
mm |
160 |
180 |
200 |
200 |
250 |
250 |
300 |
350 |
400 |
Max. Open Daylight |
mm |
260/200 |
340/280 |
410/350 |
460/400 |
500/450 |
500/450 |
550 |
650 |
700 |
Ejector Force |
tons |
1.3/1.3 |
1.3/1.3 |
1.3/1.3 |
1.3/2.1 |
3.3/3.5 |
3.3/3.5 |
4.8 |
4.8 |
4.8 |
Ejector Stroke |
mm |
45/95 |
45/95 |
45/95 |
45/145 |
75/145 |
75/145 |
75/145 |
75/145 |
75/145 |
Machine Type |
Unit |
K2S(D) |
KT-200-D(DM) |
KT-300-D(DM) |
KT-400-D(DM) |
KT-500-D(DM) |
KT-600-D(DM) |
KT-700-D(DM) |
KT-800-D(DM) |
KT-900-D(DM) |
Slide Stroke |
mm |
260 |
350 |
420 |
500 |
500 |
540 |
700 |
885 |
1000 |
Rotary Station |
- |
- |
- |
- |
- |
- |
- |
- |
- |
- |
Max. Mold Weight |
kg |
60 |
90 |
120 |
150 |
200 |
300 |
380x2 |
450x2 |
500x2 |
Station Accuracy |
mm |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
±0.02 |
Machine Type |
Unit |
K2S(D) |
KT-200-D(DM) |
KT-300-D(DM) |
KT-400-D(DM) |
KT-500-D(DM) |
KT-600-D(DM) |
KT-700-D(DM) |
KT-800-D(DM) |
KT-900-D(DM) |
Max. Hydraulic Pressure |
kg/cm2 |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
175 |
175 |
Pump Output |
liters/min |
19 |
26 |
39 |
47 |
76 |
96 |
118 |
136 |
158 |
Oil Reservoir Capacity |
liters |
80 |
100 |
130 |
150 |
180 |
200 |
350 |
410 |
720 |
Cooling Water Consumption |
liters/hr |
400-600 |
400-600 |
600-800 |
800-1000 |
1200-1500 |
1500-1800 |
1400-1600 |
1800-2000 |
2000-2200 |
Pump Motor Power |
kw |
2.2 |
3.5 |
5.5 |
7.5 |
11 |
14.7 |
18.75 |
30 |
36.7 |
Barrel Heating Power |
kw |
2 |
2.7 |
3.5 |
4.5 |
5.6 |
7.5 |
10 |
14.3 |
18 |
Total Wattage |
kw |
4.2 |
6.2 |
9 |
12 |
16.6 |
22.2 |
28.75 |
44.3 |
54.7 |
Machine Type |
Unit |
K2S(D) |
KT-200-D(DM) |
KT-300-D(DM) |
KT-400-D(DM) |
KT-500-D(DM) |
KT-600-D(DM) |
KT-700-D(DM) |
KT-800-D(DM) |
KT-900-D(DM) |
Machine Weight |
tons |
0.5/0.55 |
1.1/1.2/1.3 |
1.4/1.5/1.6 |
2.1/2.3/2.5 |
4.5/4.8/5 |
4.9/5.2/5.4 |
5.2/5.6 |
5.5/5.9 |
6.5/7.2 |
Machine Dimensions(L x W x H) |
m |
1.4x0.8x2.1 |
1.6x1.24x1.9 |
1.7x1.35x2.15 |
1.8x1.45x2.65 |
2.0x1.7x3.2 |
2.4x1.6x3.1 |
2.1x1.5x4.3 |
2.1x1.7x4.5 |
2.5x2.2x5.2 |
Shipping Weight |
tons |
0.75/0.85 |
1.3/1.5/1.9 |
1.7/1.9/2.1 |
2.6/2.9/3.2 |
5.1/5.6/5.8 |
5.6/6/6.1 |
5.6/6.3 |
5.9/6.5 |
7.2/8.0 |
Shipping Measurements(L x W x H) |
m |
1.6x1.0x2.23 |
1.8x1.45x2.1 |
1.9x1.5x2.2 |
2.1x1.7x1.5 |
4.2x2.0x1.7 |
4.6x2.2x1.8 |
4.7x2.4x1.9 |
5.0x2.4x2.1 |
6.0x2.4x2.4 |
