Classification : Special Purpose Machine
Country: Taiwan
Phone: 886-2-2281-3361
Fax: 886-2-2281-8206
Contact Person: Terry Hsieh
- With automatic inserting equipment, adopt optical sensor and vacuum testing, ensure the quality and stability of inserting products.
| Machine Type | Unit | KVH-30-D(DM) | KVH-45-D(DM) | KVH-55-D(DM) | KVH-85-D(DM) | KVH-120-D(DM) | KVH-160-D(DM) | |||||||||||||
| Screw Diameter | mm | 20 | 25 | 30 | 25 | 30 | 35 | 30 | 35 | 40 | 38 | 40 | 42 | 35 | 40 | 45 | 50 | 50 | 55 | 60 |
| Injection Pressure | kg/cm2 | 2730 | 1747 | 1213 | 2509 | 1742 | 1280 | 2170 | 1594 | 1220 | 1745 | 1575 | 1428 | 2577 | 1973 | 1559 | 1263 | 2688 | 2221 | 1866 |
| Theoretical Shot Volume | cm3 | 31 | 49 | 71 | 59 | 85 | 115 | 99 | 135 | 176 | 190 | 211 | 232 | 173 | 226 | 286 | 353 | 471 | 570 | 678 |
| Max. Shot Weight(PS) | g | 29 | 45 | 64 | 54 | 77 | 105 | 90 | 135 | 160 | 173 | 192 | 211 | 158 | 206 | 261 | 321 | 428 | 518 | 617 |
| oz | 1 | 1.6 | 2.3 | 1.9 | 2.7 | 3.7 | 3.2 | 4.3 | 5.7 | 6.1 | 6.8 | 7.4 | 5.6 | 7.3 | 9.3 | 11.3 | 15 | 18 | 22 | |
| Injection Rate | cm3/sec | 22 | 35 | 50 | 36 | 52 | 71 | 51 | 69 | 90 | 86 | 96 | 105 | 87 | 114 | 144 | 177 | 118 | 142 | 169 |
| Screw Stroke | mm | 100 | 120 | 140 | 168 | 180 | 240 | |||||||||||||
| Screw Speed Max. | rpm | 0-205 | 0-190 | 0-175 | 0-160 | 0-180 | 0-135 | |||||||||||||
| Nozzle Contact Force | tons | 2 | 2.4 | 2.6 | 3.9 | 3.3 | 7.5 | |||||||||||||
| Nozzle Retraction Stroke | mm | 140 | 180 | 200 | 300 | 300 | 360 | |||||||||||||
| Number of Temperature Control | - | 3 | 3 | 3 | 4 | 5 | 5 | |||||||||||||
| Material Hopper Capacity | | | 20 | 20 | 30 | 50 | 30 | 90 | |||||||||||||
| Machine Type | Unit | KVH-30-D(DM) | KVH-45-D(DM) | KVH-55-D(DM) | KVH-85-D(DM) | KVH-120-D(DM) | KVH-160-D(DM) |
| Clamping Force | tons | 30 | 45 | 55 | 85 | 120 | 160 |
| Opening Force | tons | 6.5 | 8.3 | 13.5 | 10.8 | 15 | 23 |
| Platen Size | mm | 520x370 | 580x430 | 650x490 | 740x500 | 840x620 | 950x700 |
| Distance Between Tie Bare | mm | 355x205 | 400x250 | 500x340 | 560x320 | 620x400 | 750x500 |
| Min. Mold Height | mm | 160/100 | 210/150 | 260/200 | 260/200 | 280/230 | 310/250 |
| Opening Stroke | mm | 180 | 200 | 200 | 250 | 250 | 300 |
| Max. Open Daylight | mm | 340/280 | 410/350 | 460/400 | 510/450 | 530/480 | 610/550 |
| Ejector Force | tons | 1.3/1.3 | 1.3/1.3 | 1.3/2.1 | 4.8 | 3.3/3.5 | 4.8 |
| Ejector Stroke | mm | 45/95 | 45/95 | 45/145 | 150 | 75/145 | 150 |
| Machine Type | Unit | KVH-30-D(DM) | KVH-45-D(DM) | KVH-55-D(DM) | KVH-85-D(DM) | KVH-120-D(DM) | KVH-160-D(DM) |
| Slide Stroke | mm | 350 | 420 | 500 | 500 | 540 | 700 |
| Rotary Station | - | - | - | - | - | - | - |
| Max. Mold Weight | kg | 90 | 120 | 150 | 200x2 | 300 | 500 |
| Station Accuracy | mm | ±0.02 | ±0.02 | ±0.02 | ±0.05 | ±0.02 | ±0.05 |
| Machine Type | Unit | KVH-30-D(DM) | KVH-45-D(DM) | KVH-55-D(DM) | KVH-85-D(DM) | KVH-120-D(DM) | KVH-160-D(DM) |
| Max. Hydraulic Pressure | kg/cm2 | 140 | 140 | 140 | 140 | 140 | 175 |
| Pump Output | liters/min | 26 | 39 | 47 | Dec-65 | 96-17 | 109-17 |
| Oil Reservoir Capacity | liters | 100 | 130 | 150 | 180 | 200 | 400 |
| Cooling Water Consumption | liters/hr | 400-600 | 600-800 | 800-1000 | 1200-1500 | 1500-1800 | 1500-1800 |
| Pump Motor Power | kw | 3.5 | 5.5 | 7.5 | 11月15日 | 14.7 | 30/22.3 |
| Barrel Heating Power | kw | 2.7 | 3.5 | 4.5 | 7.5 | 7.5 | 14.3 |
| Total Wattage | kw | 6.2 | 9 | 12 | 18.5 | 22.2 | 36.6 |
| Machine Type | Unit | KVH-30-D(DM) | KVH-45-D(DM) | KVH-55-D(DM) | KVH-85-D(DM) | KVH-120-D(DM) | KVH-160-D(DM) |
| Machine Weight | tons | 1.1/1.2/1.3 | 1.4x1.5x1.6 | 2.1/2.3/2.5 | 4/4.5/5.1 | 4.9/5.2/5.4 | 8 |
| Machine Dimensions(L x W x H) | m | 1.6x1.24x1.3 | 1.7x1.35x1.35 | 1.8x1.45x1.45 | 3.2x1.9x1.9 | 3.8x1.9x2.2 | 4.0x2.5x2.4 |
| Shipping Weight | tons | 1.3/1.5/1.9 | 1.7/1.9/2.1 | 2.6/2.9/3.2 | 4.5/5.2/6.0 | 5.6/6/6.1 | 9.5 |
| Shipping Measurements(L x W x H) | m | 1.8x1.45x1.4 | 1.9x1.5x1.45 | 2.1x1.7x1.55 | 3.4x2.1x2.1 | 4.0x2.1x2.1 | 4.2x1.9x2.2 |
