Classification : PVC Shrinkable Film Making Machine
Applications: Packaging Shrink Film
Country: Taiwan
Phone: 886-4-2359-0788
Fax: 886-4-2359-0567
Contact Person: Ms.Kuo
Inquiry Now

PVC Shrinkable file offer many excellent benefits, such as glossiness, high transparency, durability, water resistance and easy control of shrinkage. They have been applied to a wide variety of product packaging, such as foodstuff, beverage bottles, sporting goods, etc.

For over 20 years, jumbo Steel has dedicated itself to the research of production technology for PVC shrinkable film. We have made great improvements in product prescription and machine performance, upgrading the quality and efficiency of PVC shrinkable films.We have a strong background and engineering experience for whole-plant planning and equipment supply. Jumbo Steel PVC shrinkable film production equipment has been sold worldide, and has earned a reputation for its superior machine and outstanding production know-how.

In addition to supplying the most dependable machinery, we also place emphasis on the technological support and complete production upgrades. This allows our customers to start up or resume production very quickly.

Jumbo Steel has a proven tradition of pursuing excellence and improving the PVC Shrinkable Film industry, and it will continue to develop its engineering capabilities and raise industry standards.

MODEL

JS 333S

JS 334S

JS 336S

JS 336S

Feature

Material



P.V.C.

Film Thickness Range

mm

0.02 - 0.06

0.02 - 0.06

0.02 - 0.06

0.02 - 0.06

Layflat Width Range

mm

50 - 200

70 - 300

150 - 500

200 - 700

Extruding Output Range

kg/hr

4 - 10

8 - 15

15 - 30

20 - 50

Extruder

Screw dia.

m/m Ø

35

45

55

65

Screw L/D



30 : 1

25 : 1

25 : 1

25 : 1

Drining Motor

hp

VS 7 1/2

VS 10

VS 20

VS 25

Heater Capacity

kw

8.4

6.9

10.6

15

Automatic Thermo-Controller

set

5

6

6

6

Cylinder Cooling Equip



Air Blower x 3 sets

Dies

Dia.

m/m Ø

30, 40

40, 60

60, 100

80, 120

Heater Capacity

kw

2.4, 2.4

2.4, 2.6

2.6, 3

2.9, 3.5

Take up &
Inflation Unit
(water tank type)

First Take Up Roller

Ømm x mm

Ø138 x 250

Ø138 x 300

Ø165 x 450

Ø165 x 600

Heating Tank

set

1

1

1

1

Motor

hp

AC1/2x1+AC1x1 with inverter

AC1/2x1+AC1x1 with inverter

AC1x1+AC2x1 with inverter

AC1x1+AC2x1 with inverter

Take Up Roller

mm Øx mm

140 x 250

140 x 450

165 x 660

165 x 860

Take Up Speed Range

m/min

10 - 40

10 - 40

10 - 40

10 - 40

Heater

kw

11.3

13.5

18.6

23.9

Automatic Thermo-Controller

set

1

1

1

1

Water Ring

set

1

1

1

1

First Take Up

set

1

1

1

1

Winding Unit

Winding Capacity

mm Øx mm

400 x 200

400 x 400

400 x 600

400 x 800

Dc Torque Motor

hp

1/2 HP x 2

1/2 HP x 3

1/2 HP x 2,
1 HP x 1

1/2 HP x 2,
1 HP x 1

Other

Air Compressor

hp

1

1

2

2

Total Electricity

kw

30.3

34.5

52.8

68.5

Dimension L x W x H

m

4.4x1.4x2.4

5.1x1.85x3.45

4.6x1.9x3.7

6.4x2.1x3.9

Machine Weight

ton

1.8

2.4

2.7

3.8

* All specifications and design characteristics are subject to change without prior notice.
