PRM-TAIWAN
Classification : Lollipop Stick Making Machine
Country: Taiwan
Phone: 886-4-2359-0788
Fax: 886-4-2359-0567
Contact Person: Ms.Kuo
Inquiry Now
MODEL JS 285/VL JS 285/VLA
Feature Material   P.P. P.P.
Color   1 1
Stick Dia. mm Ø3.3 - Ø3.8 Ø3.3 - Ø4.0
Stick Length mm 75 – 85 or 85 - 100 72 – 90 or 90 - 100
Capacity pcs/min 700 - 1000 1100 – 1400
Extruding Output Range kg/hr 20 - 35 35 – 45
Collecting Method   Manual Automatic
Extruder Screw dia. mm Ø55 Ø55
Screw L/D   25 : 1 25 : 1
Driving Motor hp AC 15 HP + Inverter x 1 AC 15 HP + Inverter x 1
Automatic Thermo-Controller set 4 4
Vacuum
Water Tank
Vacuum Forming Device set 1 1
Vacuum Pump & Motor hp 1/2 1/2
Water Storage Tank set 1 set (8M) 1 set (8M)
Take Up &
Cutting Unit
Take Up Unit set 1 1
Motor hp AC 1 HP with Inverter AC 1 HP with Inverter
Cutting Knife set 1 (Two end cut together, with slot cutting blade) 1 (Two end cut together, with slot cutting blade)
Motor hp AC 2 HP with Inverter AC 2 HP with Inverter
Slot Waste Collection Outlet set 1 1
Digital Counter set 1 1
Collection Conveyor set 1 1
Others Air Compressor hp 2 2
Dimension LxWxH m 12 x 1 x 1.5 12 x 1 x 1.5
Machine Weight ton 2 2

* All specifications and design characteristics are subject to change without prior notice.
