Classification : JN Series
Country: Taiwan
Phone: 886-4-22815673
Fax: 886-4-22817592
Contact Person: Mr. Liu
●Hydraulic type Automatic Blow Molding Machine.
●Automatic production design.
●Heavy-Duty clamping structure design.
●Mold Open/Close/Move by precision linear guide and finished bottles come out in line for next process.
●Gearbox drive extruder directly.
●Scraps centralize management.
●PLC control with Touch Screen for time, pressure, flow,...etc.
●Diversified parison knifes and multihead choices depend on the requirement.
●Energy saving system for hydraulic system.
●Automatic production design.
●Heavy-Duty clamping structure design.
●Mold Open/Close/Move by precision linear guide and finished bottles come out in line for next process.
●Gearbox drive extruder directly.
●Scraps centralize management.
●PLC control with Touch Screen for time, pressure, flow,...etc.
●Diversified parison knifes and multihead choices depend on the requirement.
●Energy saving system for hydraulic system.
Model 型號 |
Screw diameter 螺桿直徑/ Extrusion capacity 押出量 |
Cavities 模頭數/ Center distance 中心距 |
Clamping force 鎖模力(ton) | Clamping Stroke 開關模距(mm) | Mold domension 容模尺寸(mm) |
---|---|---|---|---|---|
JN-370-2 | 75mm/100kg, 80mm/120kg | 1, 2/160mm, 3/110mm, 4/85mm | 7 | 410 - 140 | W405 x H330 |
JN-490-2 | 80mm/120kg, 90mm/180kg | 1, 2/200mm, 3/125mm, 4/100mm | 12 | 410 - 140 | W450 x H420 |
JN-640-2 | 90mm/180kg, 100mm/250kg | 1, 2/200mm, 3/160mm, 4/125mm, 6/85mm | 20 | 640 - 220 | W550 x H420 |
JN-1000-2 | 100mm/250kg | 1 | 30 | 1000 - 480 | W600 x H650 |
