Classification : Diaper - Hygiene - Tissue Bags
Country: Taiwan
Phone: 886-3-3490269
Fax: 886-3-3490220
Contact Person: Nicole Hung
Introduction
- LY-650JD is a specialized bottom sealing type diaper bag making machine which equips with reinforced-patch film sealing unit. Other accessories like easy-tear punch, round type perforation punch are available for option.
Features
- Servo-driven feeding system with one set of photocell for printed bag.
- Servo-driven flying knife system for cutting.
- Human-machine interface for easy setting.
- Patch film sealing unit.
- Heating type handle punch.
- Perforation knife for easy tearing.
- Two sets dotted sealing knives for sealing the top of the diaper bag.
| Model | Bag width (mm) | Bag length (mm) | Output | Thickness of film (mm) |
| LY-650JD | 200-750 | 130-500 | 10-60 bags/per min | 0.04-0.14 |
