Slitting And Extension Machine SE-120-N2

Classification : Yarn Feeding Equipment

FUNG CHANG INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-3-4717824

Fax: 886-3-4717702

Contact Person: Mr.Yu

Inquiry Now

Slitting and extension machine is progressive flat yarn feeding equipment for knitting machine, which replaces traditional yarn feeding modes like creel or beam.

The material is PE film which has not been extended yet.

PE film would be slit by razor blades and through the heater plate to make 7.5 times of extension, then the finished flat yarns will be driven smoothly from guide rollers directly to knitting machine.
Slitting and extension machine can make quality flat yarn so it is the best flat yarn feeding equipment for knitting machine.

Remarks:
1.Special specifications are also available.
2.Manufacturer reserves the right to change the specifications without notice.

100-1000 denier of flat yarn can be made.
Different numbers of flat yarns can be produced.
Raise the efficiency of knitting machine.
Stable yarn feeding, Prevent the twist of yarns.
Decrease the waste of raw material.

Conditions of film

The film used in slitting and extension machine must be smooth and without fold.
The thickness of film is 0.06mm ~ 0.13mm.
The film must have not been extended.
Blown film is better to the machine.

Model	SE-120-N2
Working Width	118 cm
Extension Multiple	5 ~ 10
Thickness of Washer	2 mm ~ 6 mm
Number of Film	2 Rollers (100cm Dia.)
Power Consumption	12.3 KW
Heater Capacity	2.5 KW x 2
Dimension L x W x H (mm)	3,762 x 1,550 x 2,310
L	3,762	4,142	4652
Total Power	12.3 KW	12.3 KW	18.8 KW
Tie-in Model	DR or SR-170	DR or SR-210	DR or SR-252
