Raschel Knitting Machine SR-R series

Classification : Single Bed Raschel Knitting Machine

FUNG CHANG INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-3-4717824

Fax: 886-3-4717702

Contact Person: Mr.Yu

Video Inquiry Now

Model SR-R series is Single needle bed Raschel knitting machine which design for making the Round yarn (mono yarn) in all different kind of raw material, for example Nylon, PE, PP etc.
The control panel of this series adopts inverters or servo motor to control speed which let machine operate conveniently and adjust easily.

■ Beam type yarn feeding system, save the space.
■ Adopt inverters or servo motors for machine control.
■ The quality production and flexible application.
■ Stable production speed.

■ Simple operating and maintenance.

Remarks:

Special specifications are also available.

Manufacturer reserve the right to change the specifications without notice.

Model	SR-R
Available Width	170"	210"	240"
Gauge of Needle Bed	6, 9, 12, 18G/1"
Drive Bar (Total)	2 ~ 8
Yarn Feeding Bar	2,4 or 6
Main Motor/W Inverter	7.5HP	10HP	10HP
Power Consumption	5.8KW	7.8KW	7.8KW
Yarn let off system	Beam
Dimension L x W x H (mm)	6,360 x 1,700 x 2,510	7,320 x 1,700 x 2,510	8,040 x 1,700 x 2,510
