- Horizontal structure with ergonomic design.
- With FIFO injection design, save process time and increase productivity.
|
Machine Type |
TIP-H Horizontal |
||||
|
Clamping Force |
tons |
50 |
100 |
200 |
500 |
|
Mold Opening Force |
tons |
1.7 |
2.5 |
3.4 |
17 |
|
Piston Dia. |
mm |
Ø190 |
Ø270 |
Ø355 |
Ø560 |
|
Clamping Stroke |
mm |
275 |
430 |
450 |
700 |
|
Daylight |
mm |
500 |
650 |
550 |
800 |
|
Mold Size |
mm |
H 375 X W 480 |
H 565 X W 675 |
H 505 X W 510 |
H 800 X W 800 |
|
Post Distance (L.R. X F.B.) |
mm |
335 X 230 |
455 X 345 |
260 X 660 |
820 X 820 |
|
Max. Injection Volume |
c.c. |
314 |
622 |
1000 |
3000 |
|
Max. Injection Pressure |
kg/cm2 |
1640 |
1710 |
2000 |
2200 |
