Classification : Air Cooled Series
Country: Taiwan
Phone: 886-6-6530678
Fax: 886-6-6529053
Contact Person: Reiko Huang
- High inductive electronic temperature control switch, and water pump, easy control the manu-facturing process liquid temperature(accuracy ± 0.5°C)
- With Euro-well-known brand compressor, low noise, high E.E.R
- No need cooling water tower.
- Stainless steel plank type heat exchanger. Significantly promote the cooling efficiency, can save 20% energy.
- The cold storage trough can store surplus energy according to the demand.
- Microprocessor control panel and breakdown indication lamp.
- Multiple security protected device, postponed and automatic retunn home circulated function.
- Have dual-temperature system for choice.
- With open-type stainless steel water tank, easy to clean and maintain.
- Can set water supply by manual or automatic method.
- With perfect anti-chock device and feet wheel design, easy to move.
- The plastic hollow molding/plastics runner film roller cooling.
- Plastic injection and punching molding cooling.
- All kind microprocessor control machine tools, grinders, machine centers and combined lathe of the principal axis lubrication and hydraulic system cooling.
- Laser cutting & marking machine.
- Semiconductor and electron Instruments, ultrasonic cleaning equipment.
- All kind of machine processes liquid cooling.
Model | AT –720A | ||
Temp. range | 5~40°C(Indoor ) | ||
Humidity range | 40~80% | ||
Power | 3P –220/380V –50/60Hz | ||
Coolant | R22/R407 | ||
Cooling liquid | Water | ||
Export temp | 8~30°C ± 1°C | ||
Cooling capacity 50/60Hz |
Kcal-h | 144,000/180,000 | |
BTU-h | 576,000/720,000 | ||
kw | 168/209 | ||
Water flow | L/min | 760 | |
Water pressure | Kg | 2 | |
Water piping | High pressure rubber tube, Stainless steel piping | ||
Protection system | No fuse magnetic switch, water level, against/lack phase, ultra-temp, overload protection | ||
Compressor | Kw | 11×4 | |
Cold-water inlet/outlet | 2½" | ||
Remote control | AC220V、DC 24V | ||
Color | Blue+White | ||
Dimension LxWxH | mm | 5,850 x 1,050 x 2,110 | |
Water tank | L | 500 | |
Weight | kg | 2,550 | |
*Also have the AT-A2, AT-AL, AT-AL2 system further for your choice.
We reserve the right that modification designs and technique parameter change and will not notice specially.
|
