PRM-TAIWAN
Classification : Air Cooled Series
Country: Taiwan
Phone: 886-6-6530678
Fax: 886-6-6529053
Contact Person: Reiko Huang
Inquiry Now
  • High inductive electronic temperature control switch, and water pump, easy control the manu-facturing process liquid temperature(accuracy ± 0.5°C)
  • With Euro-well-known brand compressor, low noise, high E.E.R
  • No need cooling water tower.
  • Stainless steel plank type heat exchanger. Significantly promote the cooling efficiency, can save 20% energy.
  • The cold storage trough can store surplus energy according to the demand.
  • Microprocessor control panel and breakdown indication lamp.
  • Multiple security protected device, postponed and automatic retunn home circulated function.
  • Have dual-temperature system for choice.
  • With open-type stainless steel water tank, easy to clean and maintain.
  • Can set water supply by manual or automatic method.
  • With perfect anti-chock device and feet wheel design, easy to move.
  • The plastic hollow molding/plastics runner film roller cooling.
  • Plastic injection and punching molding cooling.
  • All kind microprocessor control machine tools, grinders, machine centers and combined lathe of the principal axis lubrication and hydraulic system cooling.
  • Laser cutting & marking machine.
  • Semiconductor and electron Instruments, ultrasonic cleaning equipment.
  • All kind of machine processes liquid cooling.


Model AT-240A AT-300A
Temp. range   5~40°C(Indoor )
Humidity range   40~80%
Power   3P –220/380V –50/60Hz
Coolant   R22/R407
Cooling liquid   Water
Export temp   8~30°C ± 1°C
Cooling capacity
50/60Hz
Kcal-h 48,000/60,000 60,000/75,000
BTU-h 192,000/240,000 240,000/300,000
kw 56/70 70/87
Water flow L/min 380 380
Water pressure Kg 2
Water piping   High pressure rubber tube, Stainless steel piping
Protection system   No fuse magnetic switch, water level, against/lack phase, ultra-temp, overload protection
Compressor Kw 7.5×2 9×2
Cold-water inlet/outlet   1½"
Remote control   AC220V、DC 24V
Color   Blue+White
Dimension LxWxH mm 2,180 x 1,050 x 2,020
Water tank L 430 430
Weight kg 960 1050
Also have the AT-A2, AT-AL, AT-AL2 system further for your choice.
We reserve the right that modification designs and technique parameter change and will not notice specially.
