G Series Biocompatible Grade TPU Resins | PRM-Taiwan B2B Marketplace

Classification : Plastic Raw Materials

GREAT EASTERN RESINS INDUSTRIAL CO.,LTD.

Country: Taiwan

Phone: 886-4-23587676

Fax: 886-4-23587575

Contact Person: Duke Shih

Inquiry Now

ISOTHANE TPU resins are high quality environmental friendly materials and available in a wide range of hardnesses in polyester and polyether-based formulations. ISOTHANE exhibit the valuable characteristics of flexible rubber and rigid plastics and their wide spectrum of mechanical properties meet customers’ demands in extensive applications.

ISOTHANE TPU resins portfolio includes high transparency grades, hot melt grades, breathable film grades, anti-static grades, engineering grade, low compression grades, bio-renewable and flame retardant grades

● High Tensile Strength

● High Mechanical Property

● High Fuel & Oil Resistance

● Good Chemical Resistance

● Low Temperature Resistance

● Excellent Hydrolytic Stability

● Bio-compatibility

● Resistance To Micro-organism

Item Name	G Series
Characteristics	ISOTHANE® G Series products are high performance environment-friendly TPU based on renew able materials with various bio-based content. They exhibit excellent transparency, mechanical properties, abrasive resistance and solvent resistance. ISOTHANE® G series can be processed by extrusion and/or injection molding.
Suggested Applications	Packing Materials and Molded parts for various market segments, such as footwear, industrial, consumer goods, and Automotive.
Description	It is a renewably sourced and manufactured via a proprietary starch sugar fermentation process, and contains at least 25% biorenewable content. It delivers superior performance with improved environmental footprint versus traditional materials. These products can be injection, extrusion and blow molded.

Items	Units	ASTM	G1075AU	G1085AEU-J2	G1085AU-L	G1095AU
Specific Gravity		D-792	1.21	1.21	1.2	1.22
Hardness	Shore A	D-2240	75A	83A	75A	95A
Tensile Strength	MPa psi	D-412	15 2200	23 3300	19 2800	44 6400
@ 50% elongation	MPa psi		3 470	7 1000	4 580	14 2000
@ 100% elongation	MPa psi		4 600	8 1200	5 730	16 2200
@ 300% elongation	MPa psi		7 1000	11 1600	8 1150	20 2900
Elongation @ Break	%		1100	750	900	700
Tear Strength	N/mm lb/in	D-624 DIE C	100 570	115 650	110 630	195 1100
Bio content	wt %	D6866-08	46	28	28	32

These property values under specific test conditions as defined in the table above are for reference only.

Items	Units	ASTM	G1685A-E2	G1685A-E3	G3095AU
Specific Gravity		D-792	1.2	1.21	1.18
Hardness	Shore A	D-2240	83A	83A	95A
Tensile Strength	MPa psi	D-412	20 2900	24 350	51 7250
@ 50% elongation	MPa psi		6 870	3 450	13 1900
@ 100% elongation	MPa psi		7 1100	4 580	15 2200
@ 300% elongation	MPa psi		12 1750	7 1000	23 3350
Elongation @ Break	%		680	900	570
Tear Strength	N/mm lb/in	D-624 DIE C	120 680	80 460	195 1100
Bio content	wt %	D6866-08	33	16	25

These property values under specific test conditions as defined in the table above are for reference only.
