TUNGYU-Medium Injection Molding Machine

TIP-1000-2RT-L-250-PCD
Clamping force : 250 tons
Injection Volume: 1000 c.c.

Hightlights:
1. Stable output and synchronization by four injection cylinders design with double open side movement.
2. Vertical structure design with screw, piston and barrel in line to have straight compound flow with less pressure loss.
3. FIFO design with latest compound injection could have stable product quality.
4. Less remnant in feeding tube could save compund in purge.

Auxiliary Design:
1. Thermal oil regulator for extruder and barrel to maintain rubber temperature.
2. Saving up to 80% energy through the hydraulic servo system. (Optional)

Application Examples:
1. Automotive rubber parts
2. Shockproof rubber
3. Dust seals
4. Coupling seals
5. Shaft seals
