Computerized 6 Color Printing, Coating & Drying Machine PCD-80-06-UV
Categories : Extrusion Coating Machines
For UV lacquer, special UV oven is required, which is equipped with rapid drying mechanism to produce tubes with glossier surface. We also offer UV & heater oven, which can save electricity and without space-limit. Customers can choose either of them accordingly. Precise index ensures accuracy of every movement. Tube feeding system works with detector. Coating mechanism will not move without tubes on mandrels.
6 Color PE Tube Dry Offset Printing Coating Machine PCD-80-06-UV-L
Categories : Extrusion Coating Machines
For left oven design, there’s no space limit, which benefits tube withdrawing and in-line connection in the future. Transferring tubes automatically can lower blowing noise. This model is equipped with an extra device-sleeve printing without shoulder, and customers can choose either function when printing and save cost.
Automatic Accumulator & Transfer Control System
Categories : Extrusion Coating Machines
Automatically storage functions. Available to connect with outer diameter control unit, to separate / remove defect tube via conveyor, not into accumulator. Automatically separate / remove tubes when accumulator fully loading. Automatically transfer tubes to printing machine and heading machine.
Computerized 8 Color Printing, Coating & Drying Machine PCD-120-08H
Categories : Hot Stamping Machines
Well-devised Ink – transmission system runs well. especially in broad area printing and screen printing . Foldable ink unit is easy to clean . change color and printing plate.
8 Color PE Tube Dry Offset Printing Coating Machine PCD-80-08H-RE(UV)
Categories : Extrusion Coating Machines
Double transferring rollers design. Stopless roller adjustment design. Plate wheel outer finetune mechanism Quick release ink rollers. Printing wheel clean system (200 mm dischargeable) Sleeve Printing Plate wheel pre-register mechanisim.
Crusher
Categories : Crushing, Shredding & Granulating Equipment
Bonmart-Crusher EXTRUDER HEADING MACHINE PRINTING MACHINE CAPPING MACHINE SEALING MACHINE ACCESSORIES
LD/LLDPE Super High Speed Inflation Machine (GF-L85ES)
Categories : Blown Film Extruders
The GF-L85ES is the largest of the three GF-L ES super high speed blown film lines for LD and LLDPE film. It is specified for a maximum film width of 2200 mm and a maximum capacity of 240 KG/HR, using an 85 mm screw, a 100 HP driving motor and a 500 mm blown film die, with 8 ZONES of temperature control on the panel. The GF-L55ES and GF-L65ES cover the narrower widths in the same series. The tower fixed take-up unit has a 2300 mm roller width and runs at Max. 60 M/Min, and the single-station surface friction winder changes bobbins semi-automatically by pneumatic system. The same option list as the rest of the ES series applies, including stacked air ring, width control, corona treater, EPC or CPC edge control, oscillating take-up, double station winder, auto tension control, hydraulic unloading, heat-slitting, a second gusset unit, an in-line bag making or printing machine, and an edge-trim on-line re-use system for returning trim to the extruder. Material: LD/LLDPE Max. film width: 2200 mm Max. capacity: 240 KG/HR Extruder: 85 mm screw, 100 HP driving motor; 500 mm blown film die Temperature control: 8 ZONES Take-up: tower fixed type, 2300 mm roller width, Max. 60 M/Min Winding: single station surface friction type, semi-auto pneumatic bobbin change Options: stacked air ring, width control, corona treater, EPC/CPC, oscillating take-up, double station winder, hydraulic unloading, heat-slitting, in-line bag making/printing, edge-trim re-use
LD/LLDPE Super High Speed Inflation Machine (GF-L65ES-1)
Categories : Blown Film Extruders
The GF-L65ES-1 belongs to the GF-L ES super high speed series for LD and LLDPE film, positioned above the standard GF-L line for wider film and higher output. In the 65 mm size the line is rated for a maximum film width of 1600 mm and a maximum capacity of 180 KG/HR, with a 65 mm screw driven by a 75 HP motor and a 350 mm blown film die. Temperature is controlled in 7 ZONES from the control panel. The take-up unit is a tower fixed type with a 1600 mm roller width and a take-up speed of Max. 60 M/Min. Winding is single station, surface friction type, with semi-automatic pneumatic bobbin change. The option list is extensive: auto loader, pressure gauge, die rotating unit, LD/LLDPE die and air ring, stacked air ring, width control, corona treater, embossing roller, air chiller, vertical or horizontal oscillating take-up, edge or center position control (EPC or CPC), manual winder with air shaft, double station winder, auto tension control, hydraulic unloading, heat-slitting, second gusset unit, in-line bag making or printing machine, edge-trim winder and an edge-trim on-line re-use system. Material: LD/LLDPE Max. film width: 1600 mm Max. capacity: 180 KG/HR Extruder: 65 mm screw, 75 HP driving motor; 350 mm blown film die Temperature control: 7 ZONES Take-up: tower fixed type, 1600 mm roller width, Max. 60 M/Min Winding: single station surface friction type, semi-auto pneumatic bobbin change Options: stacked air ring, width control, corona treater, oscillating take-up, EPC/CPC, double station winder, auto tension control, in-line bag making/printing, edge-trim re-use
Corona Treater - Label Printing TRB Series
Categories : Welding & Surface Treatment Equipment
This corona treater is design for corona treatment laminating such as Laser film laminating, Label machine type, Copper aluminum foil other moralize foil label & sticker printing or other metallic film. Ceramic discharge bar, three step (Up to 9 step)
Aluminum Foil / Paper Embossing Machine-FEM-Series
Categories : Embossing Machines
-Designed for surface embossing on beer labels, aluminum foil for tobacco packaging, various beverage labels, book cover, envelops, invitation cards, congratulatory cards, packaging paper boxes. The Foil /Paper Embossing Machine will upgrade outlook effect and product quality level. aluminium
Aluminum Foil Printing Machine(WAP Series)
Categories : Rotogravure Printing Machines
In order to meet the special requirement of aluminum foil printing, the quality and R&D oriented manufacturer-- Worldly Industrial Co., Ltd., has developed the best solution for this special printing accordingly-WAP series. Considering the diverse needs of product printing, Worldly has designed the six-color printing station in printing structure, and combined a coating machine in the terminal. This coating machine has the outstanding capacity to lacquer over aluminum foil after printing to Improve printing effect, and it is also equipped with spine glue function for many different printing requirements. Also, adopts special reverse structure for aluminum foil between each color printing station, and sets up doctor blade units on both sides to enable reverse printing in any color. Easily fulfills various requirements in printing. Besides of that, adopts "Sumimoto" sectional motor system in every printing station; therefore, saving operation time and improve effect/respond time of color register during printing cylinder replacement. This machine also equips a drying tunnel system on the top of it. It is a four-sectional drying tunnel which makes drying more efficiently. Unwinding and Rewinding units are splicing materials in double shaft automatically turret type. And it is non- stop the machine when changing materials, very simple and convenient. All machine is link-controlled by High-efficiency PLC logic controller and HMI touch interface, so the controlling effect is very precise and high efficient. In addition to that, this machine also equips with automatic color register function which makes printing quality beyond perfection. As for Q.C, Worldly selects VIDEO monitoring system to achieve real-time Q.C inspection. It effectively assists printing work and improves quality Even if in high speed printing operation.
Automatic High-Speed Rotogravure Printing Machine
Categories : Rotogravure Printing Machines
This machine is designed for printing on materials such as OPP, PE, PP, PVC, shrinkable film, wrapping paper, and aluminum foil
