Single Body Die-removing Ejection Compression Molding Machine - FCS Series

Classification : PRODUCTS

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.
Country: Taiwan
Phone: 886-6-2531251
Fax: 886-6-2535271
Contact Person: Ping Shun Huang
SPEC TYPE    FCS-80 FCS-100 FCS-150 FCS-250 FCS-350 FCS-400
CLAMPING FORCE TON 80 100 150 250 350 400
PLATE SIZE MM 400x405 500x500 530x605 540x600 835x760 760x810
STROKE MM 400 410 450 450 500 520
DAYLIGHT MM 600 600 600 650 700 700
OIL TANK CAPACITY GAL 60 70 100 160 200 200
PUMP PRESSURE KGF/CM2 210 210 210 210 210 210
MOTOR HP 3 5 5 7.5 15 15
HEATER CAPACITY KW 5 6 8 10 16 16
  L 1540 1650 1780 2000 2220 2200
MACHINE DIMENSIONS MM W 1520 1730 2000 1970 2340 2420
  H 2200 2200 2250 2280 3170 3300
MACHINE WEIGHT KG 2650 3650 4700 5250 9300 9850
WRAPPING WEIGHT APPROX KG 2950 3950 5100 5850 10000 10550
CONTACT SUPPLIER
