Twin Body Vacuum Oil Hydraulic Compression Molding Machine - FBV Series

Classification : PRODUCTS

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.
Country: Taiwan
Phone: 886-6-2531251
Fax: 886-6-2535271
Contact Person: Ping Shun Huang
SPEC TYPE    FBV-100 FBV-150 FBV-200 FBV-300
CLAMPING FORCE TON 100 150 200 300
PLATE SIZE MM 450x450 500x500 550x550 600x600
STROKE MM 300 350 350 350
DAYLIGHT MM 500 550 550 600
OIL TANK CAPACITY GAL 150 150 200 200/150
PUMP PRESSURE KGF/CM2 210 210 210 210
MOTOR HP 5x2 5x2 71/2x2 10x2/10
HEATER CAPACITY KW 12 16 20 24/12
  L 3550 3750 3850 4150
MACHINE DIMENSIONS W 2030 2130 2300 2400
  H 2850 2950 3050 3350
MACHINE WEIGHT KG 7000 10000 12000 17000
WRAPPING WEIGHT APPROX KG 7600 10700 12700 18000
