Single Body Oil Hydraulic Compression Molding Machine - FCL SERIES

Classification : PRODUCTS

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.

LONG CHANG MECHANICAL INDUSTRIAL CO., LTD.
Country: Taiwan
Phone: 886-6-2531251
Fax: 886-6-2535271
Contact Person: Ping Shun Huang
SPEC TYPE    FCL-300 FCL-400 FCL-500 FCL-600 FCL-800 FLC-1000 FCL-1500
CLAMPING FORCE TON 300 400 500 600 800 1000 1500
PLATE SIZE MM 860x915 910x910 1000x1000 1100x1100 1420x1420 1520x1520 1700x1700
STROKE MM 500 540 580 610 700 720 750
DAYLIGHT MM 900 950 1000 1020 1060 1060 1100
OIL TANK CAPACITY GAL 200 250 250 300 355 420 500
PUMP PRESSURE KG/CM2 210 210 210 210 210 210 210
MOTOR HP 15 15 20 20 30 30 50
HEATER CAPACITY KW 20 27 30 30 40 50 75
  L 2400 2600 2720 2840 2970 3360 3500
MACHINE DIMENSIONS W 1700 1750 1850 1900 2270 2300 3800
  H 3200 3300 3500 3560 3900 3900 4000
MACHINE WEIGHT KG 9500 13000 17000 25000 33000 43000 65000
WRAPPING WEIGHT APPROX KG 10200 13700 18000 26800 34000 44500 66500
