TS Swing Type Clamps

Proof Pressure

275kgf/cm2

Working Pressure

180kgf/cm2

Working Temperature Range

-5~60°C

Hydraulic Fluid

ISO VG32-VG5656

Microswitch Type

Z-15G-Q-22B

Type Of Contact

Single Pole Double Throw

Rating

AC125V,20A
DC 30V,6A6A

Model

A

B

C

D

E

F

G

BB

Z

J

K

M

N

TS-4

94

27.5

95

22.5

50

28

28

52

115

28

16

230

16

TS-6

129

34.5

110

25

60

36

30

60

129

32

20

280

18

TS-10

168

35.5

150

25

100

44

35

68

168

38

20

348

22

Model

O

P

Q

R

S

T

U

V

W

X

Y

TS-4

135

24°

55

55

60.5

55

15.5

19.5

143.5

5

2.5

TS-6

150

21°

70

68

75

70

11

19

178

5

2.5

TS-10

190

36°

85

93

102.5

85

21

29

226

6

3
