Water Cooling Downstream 2-Layer Co-Extrusion Blown Film Machine

Classification : Co-Extrusion / Multilayer Blown Film Machine

CHYI YANG INDUSTRIAL CO., LTD.

CHYI YANG INDUSTRIAL CO., LTD.
Country: Taiwan
Phone: 886-3-328-8686
Fax: 886-3-328-3737
Contact Person: Renee Kuo
  1. Available for producing food packing film, special purpose film.
  2. Different composition of resin can increase film physical properties and reduce costs
  3. Equipped with two different size extruders to match A+B+A or A+B dies
  4. Designed with 2 independent motors and gearboxes for each layer film thickness control
  5. Raw material: PP, MDPE, LDPE, LLDPE, EVA, etc.

MODEL NO. MPP-45+35 MPP-55+45 MPP-65+55
Screw Diameter (mm) 25-60 55 & 45 65 & 55
Output (Kg/hr) * 15-45 30-85 50-120
Roller Width (mm) 750 900 1200
Power Required (Kw) 60 90 125
Drive Motor (HP) 25 & 10 30 & 15 40 & 30
Die Diameter (mm) 200 & 120 300 & 180 450 & 250
Machine Dimension (m) 6.5 x 3 x 5 6.7 x 3.1 x 5 7 x 3.5 x 5.3
*Output depending on film width, thickness, die size, raw material.
*For more details specification, special requirements & quotation, please kindly contact us.
