LDPE/LLDPE Blown Film Machine

Classification : Blown Film Extrusion Machine

Applications: Packaging HDPE Net Film

CHYI YANG INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-3-328-8686

Fax: 886-3-328-3737

Contact Person: Renee Kuo

Video Inquiry Now

Barrel and Screw have special treatment and forced feeding for better output
Double lip air ring & better cooling system to support the high speed capacity
Can produce LDPE, LLDPE and shrinkable film
Slitting device and double winder (up-and-down & back-to-back type) is offered to produce single layer film rolls.
Optional Rotating die device is making uniform thickness film for printing & laminating purpose
Optional Co-speed controller matches same speed for take-up unit and winder to avoid film to be stretched
Purchasing HDPE die can produce HDPE film
Fully automatic winder makes machine automatically & save time of operators
We didn’t show all our models, please don’t hesitate to contact us for bigger extruders.

MODEL NO.	LLDPE-45FTE	LLDPE-55FTE	LLDPE-65FTE	LLDPE-75FTE	LLDPE-85FTE
Screw Diameter (mm)	45	55	65	75	85
Output (Kg/hr) *	30-70	50-105	70-160	80-180	90-220
Roller Width (mm)	750	1000	1200	1500	2200
Power Required (Kw)	27	42	52	65	120
Drive Motor (HP)	25	40	50	60	75
LDPE Die Diameter (mm)	100 or 150	120 or 200	150 or 300	250 or 500	400 or 600
Machine Dimension (m)	4.5 x 2.5 x 4.5	5.2 x 2.7 x 5.5	5.3 x 2.9 x 6	5.5 x 3 x 7.2	6 x 3.7 x 8

* Output depending on film width, thickness, die size, raw material.
* For more details specification, special requirements & quotation, please kindly contact us
