PE STRETCH CASTING FILM EXTRUSION MACHINE

Classification : Cast Film Extrusion Machine

CHYI YANG INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-3-328-8686

Fax: 886-3-328-3737

Contact Person: Renee Kuo

Video Inquiry Now

T-Die Extruder machine can produce waterproof PE film for baby diaper, sanitary napkin, folders, table cloths, medical film, etc.
Film thickness 0.03~1 mm
Equipped with a fully automatic winder with cutting and changing rolls functions
Hydraulic screen changer for short maintenance stop
We didn’t show all our models, please don’t hesitate to contact us for bigger extruders.

MODEL NO.	EXP-65TN	EXP-75TN	EXP-85 TN	EXP-100TN	EXP-120TN
Screw Diameter (mm)	65	75	90	100	120
Output (Kg/hr) *	30-70	40-80	50-90	60-100	90-200
Roller Width (mm)	900	1200	1500	1800	2200
Drive Motor (HP)	40	50	60	75	100
T-Die Width (mm)	900	1200	1500	1800	2200
Machine Dimension (m)	7.6 x 2.3 x 2	8.5 x 2.6 x 2	9.1 x 2.9 x 2	10 x 3.2x 2.2	11 x 3.5x 2.3

*Output depending on film width, thickness, die size, raw material.
*For more details specification, special requirements & quotation, please kindly contact us.
