Garment bag perforating on roll making machine

Classification : Bag on Roll Bag Making Machine

SING SIANG MACHINERY CO., LTD.

SING SIANG MACHINERY CO., LTD.
Country: Taiwan
Phone: 886-6-356-3297
Fax: 886-6-356-7267
Contact Person: Angela Yang
1. Conveyer Stacker.
2. Second Set of In Feed Roller.
3. Garment Cover Sealing Device.
4. Front Thick Bags Sealing Device.
5. Punching Device.
6. Rear Instant Air Cooling Device.
7. Static Shielding Bags Production Device.
8. Packing List Envelopes Production Device.
9. Calendar Bags Flocking Attachment Device.
10. Glove Bags.
Model SHCG-20 SHCG-24 SHCG-30 SHCG-36 SHCG-42 SHCG-50 SHCG-60 SHCG-75
Output Cycle/min Max 140 Max 140 Max 140 Max 140 Max 100 Max 100 Max 80 Max 80
Bag Width 480 m / m 550 m / m 725 m / m 860 m / m 1010 m / m 1210 / m 1470 / m 1850 / m
Standard Bag Length Max 1820 m/m Max 1820 m/m Max 1820 m/m Max 1820 m/m Max 1820 m/m Max 2540 m/m Max 2540 m/m Max 2540 m/m
Servo Motor One Set
Main Motor 2H4P 2H4P 2H4P 2H4P 2H4P 2H4P 2H4P 2H4P
Inverter 3 HP 3 HP 3 HP 3 HP 3 HP 3 HP 3 HP 3 HP
Heater 2.0 KW 2.2 KW 2.5 KW 3.0 KW 3.5 KW 4.0 KW 4.5 KW 5.0 KW
Power Consumption 3.5 KW 3.7 KW 4.0 KW 5.2 KW 5.7 KW 6.2 KW 6.7 KW 7.2 KW
Machine Dimension (LxWxH) 3300 x 1170 x 1440 3300 x 1270 x 1440 3300 x 1420 x 1440 4200 x 1570 x 1650 4200 x 1730 x 1650 4200 x 1930 x 1650 4200 x 2190 x 1650 4200 x 2540 x 1650
Machine Weight 700 kg 800 kg 900 kg 1000 kg 1100 kg 1200 kg 1300 kg 1400 kg
Gross Weight 930 kg 1100 kg 1200 kg 1300 kg 1400 kg 1500 kg 1600 kg 1700 kg
