Corona Treater -T Series / For Blown Film Line
Categories : Blown Film Extruders Lines
Corona treater is a surface modification technique for adhesion improving treatment and increase dyne level. It uses a low temperature corona discharge plasma to impart changes in the properties of a surface. Materials such as plastics, cloth, or paper may be passed through the corona plasma curtain in order to change the surface energy of the material. All materials have an inherent surface energy. Surface treatment systems are available for virtually any surface format including dimensional objects, sheets and roll goods that are handled in a web format. Corona treatment is a widely used surface treatment method in the plastic film, extrusion, and converting industries. It is also known as plastic surface treater, surface corona treater, air plasma, corona discharge treatment, corona treating, Corona-discharge Plastic Surface Treatment Equipment, corona treatment machine, corona treatment device and corona treatment. Application Extrusion: ．Blown film extrusion / Blown film machine / ABA co-extrusion / Inflation machine ．Cast film / sheet extrusion / Extrusion coating / coating lamination / Extrusion lamination / tandem extrusion lamination Printing: ．Inline Printing press / printing machine / Rotogravure printing machines / woven bag printing / label printing / Solvent printing / water base printing / Flexo printing / T shirt bag printing Converting ．Slitting rewinder / coating / wet lamination / dry lamination / hot lamination / solventless lamination / Rotogravure coating machines /gluing / bonding / tandem lamination Model CH-800S / CH-1000S / CH-1200S / CH-1500S / CH-2000S / CH-3000S / CH-5000S CH-800T / CH-1000T / CH-1200T / CH-1500T / CH-2000T / CH-2KT CH-3000T / CH-5000T / CH-8000T CH-3KT / CH-5KT / CH-8KT / CH-10KT / CH-12KT / CH-15KT / CH-20KT CH-3KD / CH-5KD / CH-8KD / CH-10KD / CH-12KD / CH-15KD / CH-20KD Substrate material HDPE, LDPE, LLDPE, MLLDPE, PET, PVC, PP, OPP, CPP, BOPP, PI, PS, PC, EVA, Nylon, PTFE, PU, TPO, TPE, TPO, Bio degradable , Biodegradable, Bio-degradable, Stretch film PE woven, PP woven Hollow profile sheet, corrugated sheet, Cartonplast, Polyflute, Coroplast , FlutePlast, IntePro, Proplex, Correx, Twinplast, Corriflute, Corflute Metalized film, FPC, Foil, copper foil, electrodepositedcopperfoil, CCL Non woven, Melt blown, Fabric, textile
Twin Die LDPE Zipper Film Blown Machine
Categories : Blown Film Extruders Lines
* Zipper film system - Zipper extruded at the same time of film extrusion. Can be in-lined by extuder - printer - bag making. * Double bag system - Small bags are extruded with 2 zippers and cold-slitted on bag making machine. * Double die systems - Single screw extrusion with 2 die heads for extrusions.
LDPE Zipper Blown Film Machine With Rotogravure In Line Printing Machine (AEZ-45/55+ARP800i)
Categories : Blown Film Extruders Lines
LDPE ZIPPER BLOWN FILM MACHINE with ROTOGRAVURE IN LINE PRINTING MACHINE(AEZ-45/55+ARP800i)
LDPE Zipper Film Blown Machine With Rotogravure In Line Printing Machine
Categories : Blown Film Extruders Lines
LDPE Zipper Film Blown Machine With Rotogravure In Line Printing Machine ● Model：AEZ-45 ● Applicable Material：LDPE ● Film Width：60~300mm ● Screw Diameter：φ45mm
LDPE High Speed Zipper Blown Film Machine(AEZ-45/55)
Categories : Blown Film Extruders Lines
LDPE HIGH SPEED ZIPPER BLOWN FILM MACHINE(AEZ-45/55)
Zipper Bag Blown Film Machine
Categories : Blown Film Extruders Lines
Designed to produce single line & double lines zipper bags, double zipper bags are upto the bags size & die. Different range film length should match different die & cooling ring Color injection extruder is an option.
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-40/45
Categories : Blown Film Extruders Lines
The KMTL-40/45 is a two-layer high-speed plastic inflation machine for blown film extrusion of HDPE, LDPE, and LLDPE resins, producing 2-layer PE film up to 800 mm (KMTL-40) or 900 mm (KMTL-45) wide for applications such as car film and food plastic wrap. The KMTL-40 runs twin Ø40mm screws with a 20 HP AC driving motor and 6-zone auto thermo control, producing film at 15-70 kgs/hr; the KMTL-45 runs twin Ø45mm screws with the same 20 HP AC driving motor and 2-zone auto thermo control, producing film at 20-90 kgs/hr. Both models operate at a 26:1 L/D ratio and a take-up speed of 70 m/min. Models: KMTL-40 / KMTL-45 Suitable material: HDPE/LDPE/LLDPE (both) Film thickness: 0.010-0.15 mm (both) Film width range: KMTL-40 800 mm; KMTL-45 900 mm Film output: KMTL-40 15-70 kgs/hr; KMTL-45 20-90 kgs/hr Screw diameter/type: KMTL-40 Ø40mm x2; KMTL-45 Ø45mm x2 (L/D ratio 26:1 both) Driving motor: AC 20 HP + Inverter (both) Take-up speed: 70 m/min (both) Machine dimension: KMTL-40 450×200×400 cm; KMTL-45 470×220×450 cm
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-55
Categories : Blown Film Extruders Lines
The KMTL-55 is a two-layer HDPE/LDPE/LLDPE high-speed plastic inflation (blown film extrusion) machine, producing two-layer PE film at widths up to 1,400 mm for applications such as car film and food plastic wrap. The extruder is built around a Ø 55mm x 2 screw with a 28:1 L/D ratio and a 30 HP AC driving motor with inverter. The die unit uses a Ø350 mm die and Ø400 mm air ring. Film thickness ranges from 0.025 to 0.15 mm, output reaches 20-150 kgs/hr, and the take-up unit runs at speeds up to 45 m/min. Model: KMTL-55 Suitable material: HDPE/LDPE/LLDPE Film thickness: 0.025-0.15 mm Film width range: 1400 mm Film output: 20-150 kgs/hr Screw diameter/type: Ø 55mm x 2, L/D ratio 28:1 Driving motor: AC 30 HP + Inverter Die diameter: Ø350 mm / Air ring diameter: Ø400 mm Machine dimension: 500x500x800 cm
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-65
Categories : Blown Film Extruders Lines
The KMTL-65 is a two-layer HDPE/LDPE/LLDPE high-speed plastic inflation (blown film extrusion) machine, producing two-layer PE film at widths up to 2,000 mm for applications such as car film and food plastic wrap. The extruder uses a Ø 65mm x 2 screw with a 28:1 L/D ratio and a 50 HP AC driving motor with inverter. The die unit is fitted with a Ø500 mm die and Ø550 mm air ring. Film thickness ranges from 0.03 to 0.15 mm, output reaches 60-250 kgs/hr, and the take-up unit runs at speeds up to 40 m/min. Model: KMTL-65 Suitable material: HDPE/LDPE/LLDPE Film thickness: 0.03-0.15 mm Film width range: 2000 mm Film output: 60-250 kgs/hr Screw diameter/type: Ø 65mm x 2, L/D ratio 28:1 Driving motor: AC 50 HP + Inverter Die diameter: Ø500 mm / Air ring diameter: Ø550 mm Take-up speed: 40 m/min
TWIN HEAD HDPE PLASTIC INFLATION MACHINE : KMH-45T
Categories : Blown Film Extruders Lines
The KMH-45T is a twin head HDPE plastic inflation machine producing double output HDPE film, with combined yield up to 48 kg/hour, width up to 400 mm per head, and thickness between 0.008 and 0.06 mm.Each head runs a Ø45 mm screw with a 28:1 L/D ratio and 9.6 kw heating capacity, cooled by a 1/8 HP x 3 barrel cooling fan and driven by a 20 HP AC motor with inverter. The die unit (2 units) uses Ø50 mm dies with Ø100 mm air rings and a 3 HP cooling blower, and the take-up unit runs at speeds up to 85 m/min.Model: KMH-45TSuitable material: HDPEFilm thickness: 0.008 ~ 0.06 mmFilm width range: 400 mm × 2Film output: 24 kgs/hr × 2Screw diameter/type: Ø45 mm x 2, L/D ratio 28:1Driving motor: AC 20 HP + InverterDie diameter: Ø50 mm x 2 / Air ring diameter: Ø100 mm x 2Take-up speed: 85 m/min
TWIN HEAD(A/B/A LAYER) HDPE / LDPE / LLDPE PLASTIC INFLATION MACHINE : KMTL-4545T
Categories : Blown Film Extruders Lines
The KMTL-4545T is a twin head (A/B/A layer) HDPE/LDPE/LLDPE plastic inflation machine that produces double output film at widths up to 400 mm per head, for applications such as car film and food plastic wrap.Each head runs a Ø 45mm screw with a 28:1 L/D ratio, driven by a 20 HP AC motor with inverter. The ABA die unit uses Ø60/80 mm dies with a Ø120 mm air ring per head. Film thickness ranges from 0.010 to 0.10 mm, output reaches 10-32 kgs/hr per head, and the take-up unit runs at speeds up to 85 m/min.Model: KMTL-4545TSuitable material: HDPE/LDPE/LLDPEFilm thickness: 0.010-0.10 mmFilm width range: 400 mm x 2Film output: 10-32 kgs/hr x 2Screw diameter/type: Ø 45mm x 2, L/D ratio 28:1Driving motor: AC 20 HP + InverterDie diameter (ABA): Ø60/80 mm x 2 / Air ring diameter: Ø120 mm x 2Take-up speed: 85 m/min
Three-Layer Co-Extrusion Blown Film Machine KS-ML3-95-110-95
Categories : Blown Film Extruders Lines
Wide-Width, High-Output Three-Layer Blown Film Solution for Packaging Applications The KS-ML3-95-110-95 Three-Layer Co-Extrusion Blown Film Machine is a high-performance blown film line developed by KUNG HSING Plastic Machinery for lamination films, shrink films, and food packaging applications. By integrating European key components, intelligent control systems, and advanced cooling and thickness measurement technologies, this machine delivers stable production, excellent gauge uniformity, and consistent film quality, even under wide-width and high-output operating conditions.
THREE LAYER BLOWN FILM EXTRUDER PLASTIC INFLATION MACHINE : KMTL-E3
Categories : Blown Film Extruders Lines
The KMTL-E3 is a three-layer HDPE/LDPE/LLDPE/mLDPE blown film extrusion line offered in three sizes, with film widths from 900 to 1,800 mm and thickness from 0.02 to 0.20 mm, suited to car film, food packaging, and courier bags.The line comprises the KMTL-40-45-40 E3, KMTL-45-55-45 E3, and KMTL-55-65-55 E3 configurations, with screw diameters of Ø 40-45-40 mm, Ø 45-55-45 mm, and Ø 55-65-55 mm (28:1 L/D ratio), driven by 15-20-15 HP, 20-30-20 HP, and 30-50-30 HP AC motors with inverter. Film output ranges from 110 to 250 kgs/hr across the three sizes.Model line: KMTL-40-45-40 E3 / KMTL-45-55-45 E3 / KMTL-55-65-55 E3Suitable material: HDPE/LDPE/LLDPE/mLDPEFilm thickness: 0.02-0.15 mm / 0.025-0.20 mm / 0.03-0.20 mmFilm width range: 900 mm / 1400 mm / 1800 mmFilm output: 110 kgs/hr / 150 kgs/hr / 250 kgs/hrScrew diameter/type: Ø 40-45-40 mm / Ø 45-55-45 mm / Ø 55-65-55 mm, L/D ratio 28:1Driving motor: AC 15-20-15 HP / 20-30-20 HP / 30-50-30 HP + InverterDie diameter: Ø200 mm / Ø300 mm / Ø500 mmTake-up speed: 65 m/min / 45 m/min / 40 m/min
Three-Layer Co-Extrusion Blown Film Machine
Categories : Blown Film Extruders Lines
The KS-ML3-50-65-50 Three-Layer Co-Extrusion Blown Film Machine is a flexible and cost-efficient blown film line developed by KUNG HSING Plastic Machinery for packaging films and general-purpose films.Designed to process 25–50% recycled materials, this system integrates precise gravimetric control, stable cooling technology, and reliable take-up and winding systems to ensure consistent film quality, stable thickness control, and efficient production performance.
Three-Layer HDPE Co-Extrusion Blown Film Machine
Categories : Blown Film Extruders Lines
The KS-ML3-45-55-45 Three-Layer HDPE Co-Extrusion Blown Film Machine is a high-efficiency blown film line developed by KUNG HSING Plastic Machinery for liner bags and general packaging bag applications.Engineered for HDPE- and MDPE-based formulations, with excellent adaptability to recycled materials, this machine delivers stable film formation, consistent bag quality, and reliable winding performance, even at thin gauges ranging from 10 to 50 microns.
Blown Film Machine for Shrink Hood Film
Categories : Blown Film Extruders Lines
Blown Film Machine for Shrink Hood Film
3 Layer Blown Film Machine for Shrink Hood Film
Categories : Blown Film Extruders Lines
3 Layer Blown Film Machine for Shrink Hood Film
Seven-Layer Co-Extrusion Blown Film Machine
Categories : Blown Film Extruders Lines
High Output Seven-Layer Blown Film Solution with Dual Cooling Technology KS-ML7-55-55-55-55-55-55-55 The KS-ML7-55 Seven-Layer Co-Extrusion Blown Film Machine is a high-performance blown film line developed by KUNG HSING Plastic Machinery for advanced packaging film applications. The KS-ML7-55 ensures excellent gauge uniformity, stable mechanical properties, and consistent film quality, even under high-output production conditions.
Rotary Die Head & Rotator
Categories : Extrusion Dies and Die Heads
＋For LDPE / LLDPE blown film machine. ＋To stablely control the product thickness, enhance cooling effect and improve product quality.
P.P Blown Film (Tubular) Extrusion Line
Categories : Blown Film Extruders Lines
Ming Jilee's MGPP-Serial P.P Blown Film (Tubular) Extrusion Line melts PP granules and extrudes them through an annular die into a tube of molten film, which is inflated to set the lay flat width before being wound into roll form for downstream converting. The series spans four models, MGPP-45 through MGPP-75, processing P.P. granules in a thickness range of 0.02 - 0.08 mm. Lay flat film width runs from 100 - 400 mm on the MGPP-45 up to 550 - 950 mm on the MGPP-75, with output from 10 - 35 kg/hr on the smallest model up to 20 - 100 kg/hr on the largest. Machine dimension scales with model, from 4 (L) × 1.6 (W) × 3.4 (H) m on the MGPP-45 to 7.52 (L) × 2.2 (W) × 5.2 (H) m on the MGPP-75. Applicable resin: P.P. granules Thickness Range: 0.02 - 0.08 mm Lay Flat Film Width: MGPP-45 100 - 400 mm / MGPP-55 150 - 550 mm / MGPP-65 300 - 650 mm / MGPP-75 550 - 950 mm Output: MGPP-45 10 - 35 kg/hr / MGPP-55 20 - 50 kg/hr / MGPP-65 20 - 60 kg/hr / MGPP-75 20 - 100 kg/hr Machine Dimension (MGPP-45): 4 (L) × 1.6 (W) × 3.4 (H) m Machine Dimension (MGPP-75): 7.52 (L) × 2.2 (W) × 5.2 (H) m
P.P. Film Inflation Machine (GF-P65)
Categories : Blown Film Extruders Lines
The GF-P65 is a P.P. (polypropylene) tubular film inflation machine, a blown film line adapted for polypropylene, which needs a sizing and cooling arrangement different from polyethylene film. It is one of four sizes in the GF-P series, from the GF-P45 to the GF-P75, and is specified for a maximum film width of 800 mm with a 65 mm extruder driven by a 30 HP motor with inverter, a 350 mm die with a single lip air ring, a 2 HP inverter-controlled blower, 5 PCES of sizing ring and a hot air type drying system. Maximum capacity is 80 kg/hr. Control is from an independent switch board and the roller width is 900 mm. Options include an auto loader, hopper dryer, manual screen changer, pressure gauge, die rotating unit, corona treater, static eliminator, 4-spindle winder, air shaft and water chiller, so the machine can be built up for printed or multi-roll production of PP tubular film. Type: P.P. tubular film inflation machine Material: P.P. (Polypropylene) Max. film width: 800 mm Extruder: 65 mm, 30 HP motor with inverter Die: 350 mm with single lip air ring; blower 2 HP with inverter; sizing ring 5 PCES; hot air type drying system Max. capacity: 80 kg/hr; roller width 900 mm Options: auto loader, hopper dryer, manual screen changer, die rotating unit, corona treater, static eliminator, 4-spindle winder, air shaft, water chiller
