THREE LAYER BLOWN FILM PLASTIC INFLATION MACHINE KMTL-E3

Classification : Plastic Inflation Machine

KANG CHYAU INDUSTRY CO., LTD.

KANG CHYAU INDUSTRY CO., LTD.
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang

SUITABLE MATERIAL: HDPE/LDPE/LLDPE/MLDPE


KMTL-E3

Film Width: 500-1800 mm
Screw Dia.: Ø 40-45-40/45-55-45/55-56-55 mm



MODEL KMTL-40-45-40 E3 KMTL-45-55-45 E3 KMTL-55-65-55 E3
SUITABLE MATERIAL HDPE/LDPE/LLDPE/mLDPE HDPE/LDPE/LLDPE/mLDPE HDPE/LDPE/LLDPE/mLDPE
FILM THICKNESS 0.02-0.15 mm 0.025-0.20 mm 0.03-0.20 mm
FILM WIDTH RANGE 900 mm 1400 mm 1800 mm
FILM OUTPUT 110 kgs/hr 150 kgs/hr 250 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE Ø 40/45/40 mm Ø 45/55/45 mm Ø 55/65/55 mm
SCREW L/D RATIO 28:1 28:1 28:1
HEATING CAPACITY 24.6 kw 34.3 kw 43.7 kw
AUTO THERMO CONTROL 11 zone 13 zone 17 zone
BARREL COOLING FAN 1/8 HP x 6 1/8 HP x 9 1/8 HP x 9
DRIVING MOTOR AC 15-20-15 HP + Inverter AC 20-30-20 HP + Inverter AC 30-50-30 HP + Inverter
DIE UNIT
DIE DIAMETER Ø200 mm Ø300 mm Ø500 mm
AIR RING DIAMETER Ø250 mm Ø350 mm Ø550 mm
HEATING CAPACITY 19.8 kw 24.6 kw 28.8 kw
AUTO THERMO CONTROL 3 zone 4 zone 4 zone
COOLING BLOWER 5 HP 7 1/2 HP 10 HP
TAKE-UP UNIT
TAKE-UP ROLLER 1100 mm 1600 mm 2000 mm
EFFECTIVE WIDTH 900 mm 1400 mm 1800 mm
TAKE-UP MOTOR AC 1/2 HP AC 1 HP AC 2 HP
TAKE-UP SPEED 65 m/min 45 m/min 40 m/min
WINDING UNIT
ROLLER WIDTH 1100 mm 1600 mm 2000 mm
WINDING WIDTH 900 mm 1400 mm 1800 mm
WINDING MOTOR DC 1 HP DC 1 HP DC 2 HP
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
