HDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMH-65

Classification : Plastic Inflation Machine

Applications: Packaging Grocery Bags

KANG CHYAU INDUSTRY CO., LTD.

Country: Taiwan

Phone: 886-2-22856880

Fax: 886-2-22856883

Contact Person: Gina Kang

E-catalog Inquiry Now

The KMH-65 is a high-speed HDPE blown film extrusion line built for wide-format film production, used in applications such as plastic shopping bags. Within the plastic inflation machinery process, HDPE resin is extruded and inflated into tubular film through a die and air ring, then flattened and wound. The KMH-65 produces HDPE film in 0.008-0.10 mm thickness and up to 1300 mm width, with output between 20-80 kgs/hr.

The extruder runs a Ø 65 mm screw at a 26:1 L/D ratio with 4-zone auto thermo control on the barrel, driven by an AC 50 HP motor with inverter. The die unit uses a Ø100/150 mm die paired with a Ø150/200 mm air ring, and the take-up section reaches speeds up to 75 m/min.

KMH-65

Film Width500-1300 mm

Screw Dia.Ø 65 mm

Suitable MaterialHDPE

KMH-65 model High-speed HDPE Blown Film Extrusion Line

MODEL	KMH-65
SUITABLE MATERIAL	HDPE
FILM THICKNESS	0.008-0.10 mm
FILM WIDTH RANGE	1300 mm
FILM OUTPUT	20-80 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE	Ø 65 mm
SCREW L/D RATIO	26:1
HEATING CAPACITY	14.7 kw
AUTO THERMO CONTROL	4 zone
BARREL COOLING FAN	1/8 HP×2
DRIVING MOTOR	AC 50 HP + Inverter
DIE UNIT
DIE DIAMETER	Ø100/150 mm
AIR RING DIAMETER	Ø150/200 mm
HEATING CAPACITY	10.6 kw
AUTO THERMO CONTROL	2 zone
COOLING BLOWER	5 HP
TAKE-UP UNIT
TAKE-UP ROLLER	1500 mm
EFFECTIVE WIDTH	1400 mm
TAKE-UP MOTOR	AC 1 HP
TAKE-UP SPEED	75 m/min
ELEVATING MOTOR
WINDING UNIT
ROLLER WIDTH	1500 mm
WINDING WIDTH	1400 mm
WINDING MOTOR	DC 1 HP
MACHINE DIMENSION	600×400×600 cm
