TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE KMTL- Series

Classification : Plastic Inflation Machine

KANG CHYAU INDUSTRY CO., LTD.

KANG CHYAU INDUSTRY CO., LTD.
Country: Taiwan
Phone: 886-2-22856880
Fax: 886-2-22856883
Contact Person: Gina Kang

SUITABLE MATERIAL: HDPE/LDPE/LLDPE


KMTL-40/45

Film Width: 500-900 mm
Screw Dia.: Ø 40/45 mm*2


KMTL-55

Film Width: 500-1400 mm
Screw Dia.: Ø 55 mm*2


KMTL-65

Film Width: 500-2000 mm
Screw Dia.: Ø 65 mm*2



MODEL KMTL-40 KMTL-45 KMTL-55 KMTL-65
SUITABLE MATERIAL HDPE/LDPE/LLDPE HDPE/LDPE/LLDPE HDPE/LDPE/LLDPE HDPE/LDPE/LLDPE
FILM THICKNESS 0.010-0.15 mm  0.010-0.15 mm 0.025-0.15 mm  0.03-0.15 mm
FILM WIDTH RANGE 800 mm 900 mm 1400 mm 2000 mm
FILM OUTPUT 15-70 kgs/hr 20-90 kgs/hr 20-150 kgs/hr 60-250 kgs/hr
EXTRUDER UNIT
SCREW DIAMETER/TYPE Ø 40mm x 2 Ø 45mm x 2 Ø 55mm x 2 Ø 65mm x 2
SCREW L/D RATIO 26:01:00 26:01:00 28:01:00 28:01:00
HEATING CAPACITY 13.2 kw 17.2 kw 24 kw 29.4 kw
AUTO THERMO CONTROL 6 zone 2 zone 6 zone 8 zone
BARREL COOLING FAN 1/8 HP x 2 1/8 HP x 4 1/8 HP x 4 1/8 HP x 8
DRIVING MOTOR AC 20 HP + Inverter AC 20 HP + Inverter AC 30 HP + Inverter AC 50 HP + Inverter
DIE UNIT
DIE DIAMETER Ø80/175 mm Ø100/200 mm Ø350 mm Ø500 mm
AIR RING DIAMETER Ø120/200 mm  Ø150/250 mm Ø400 mm Ø550 mm
HEATING CAPACITY 6.2 kw 10 kw 18.4 kw 24 kw
AUTO THERMO CONTROL 2 zone 3 zone 3 zone 3 zone
COOLING BLOWER 3 HP 5 HP 7 1/2 HP 10 HP
TAKE-UP UNIT
TAKE-UP ROLLER 1000 mm 1100 mm 1500 mm 2200 mm
EFFECTIVE WIDTH 900 mm 1000 mm 1400 mm 2000 mm
TAKE-UP MOTOR AC 1/2 HP AC 1/2 HP AC 2 HP AC 3 HP
TAKE-UP SPEED 70 m/min 70 m/min 45 m/min 40 m/min
ELEVATING MOTOR AC 1/2 HP AC 1/2 HP
WINDING UNIT
ROLLER WIDTH 1000 mm 1100 mm 1500 mm 2200 mm
WINDING WIDTH 900 mm 1000 mm 1400 mm 2000 mm
WINDING MOTOR DC 1 HP DC 1 HP DC 1 HP DC 2 HP
MACHINE DIMENSION 450x200x400 cm 470x220x450 cm 500x500x800 cm
* Remark: The above machine specification and production range can be changed without any notice due to kind of different application.
