Twin Screw Parallel Counter-rotating Extruder

Classification : Extruders

TWIN SCREW INDUSTRIAL CO., LTD.

Country: Taiwan

Phone: 886-6-5014056

Fax: 886-6-5013805

Contact Person: Mercedes Su

Inquiry Now

● High specific output
● Outstanding melt homogeneity
● Maintenance-free, closed screw temperature control system
● Wide processing range thanks to metering and stuffing device
● Low wear thanks to low screw speed

● Gentle politicizing thanks to longer screw and barrel

PC Base machine operation - M Series Plastic Machine controller

Motor interlock function

12 Zones PID temperature control (Optional 24 zones) oil cooling, blower cooling control

PLC ladder logic program

Alarm record function

Chinese/English language change

Tradition operation-control type

Model	Screwdia	L/D	Drive Power	Screw R.P.M	Barrel Heater Power	Total Power	Max Output	L×W×H	Weight
Model	Screwdia	L/D	Drive Power	Screw R.P.M	Barrel Heater Power	Total Power	Max Output	L×W×H	Weight
TSE-75	Ø75 mm	25:01:00	40 HP	35-40	27 KW	64 KW	200~300 kg/hr	3960×1400×2360mm	3600 kg
TSE-90	Ø90 mm	25:01:00	75 HP	35-44	37 KW	90 KW	300~500 kg/hr	4670×1590×2420 mm	4400 kg
TSE-110	Ø107 mm	25:01:00	100 HP	37	48 KW	130 KW	500~700 kg/hr	5140×1750×2480 mm	6700 kg
TSE-130	Ø132 mm	25:01:00	150 HP	37	79 KW	205 KW	950~1200 kg/hr	6380×2260×2700 mm	9500 k
