Classification : Automotive Application
Country: Taiwan
Phone: 886-49-2253588
Fax: 886-49-2252998
Contact Person: Sales Department
- Equipped with servo motor for energy saving, product quality stabilization and operation efficiency.
- Accurate loader and unloader mechanism with bumper function for excellent alignment.
- Heating platen with special channel design for temperature uniform distribution to have best tire quality.
- Rear pneumatic inflator (option): Equipped at the rear side of main frame to operate in automation. After curing process the inflation tire will be cooling and forming to prevent body from deformation and make sure quality.
|
Machine Type |
|
TPS-175 |
|
Clamping Force |
ton |
80-175 |
|
Heating Platen |
mm |
Ø1200 |
|
Daylight |
mm |
2427 |
|
Stroke |
mm |
1800 |
|
Pulling Stroke |
mm |
650 |
|
No. of Mold |
cav. |
2 |
|
Raw Tire I.D. |
inch |
13-20 |
|
Mold O.D. |
mm |
1020 |
|
Mold Height |
mm |
250-550 |
|
Max. Working Pressure |
Kg/cm2 |
210 |
|
Max. Steam Pressure |
Kg/cm2 |
15 |
|
Max. Inner Pressure |
Kg/cm2 |
25 |
|
Dimension |
mm |
L 4800 x W 3871 x H 6553 |
