- Main frame with J type design to save the footprint area.
- Full operation on HMI with rotation arm to comply with ergonomic design.
- Optimization of temperature regulator design with orderly tubes to save space and improve operation noise.
- Equipped with guide sleeve on screw inlet to improve the rubber feeding capacity.
- Screw motor with reverse function, easily remove the residual rubber out of extruder
- Intelligent integration solution→https://youtu.be/gyjszeMGQLo
|
Machine Type |
TIP-L Vertical |
|||||||
|
Injection Unit |
||||||||
|
Injection Volume |
c.c. |
100 |
500 |
1000 |
2000 |
3000 |
3000 |
|
|
Injection Pressure |
kg / cm² |
1500~2000 |
||||||
|
Injection Flow |
c.c. / sec |
35 |
65 |
76 |
134 |
175 |
175 |
|
|
Clamping Unit |
||||||||
|
Clamping Force |
tons |
100 |
150 |
200 |
250 |
350 |
500 |
|
|
Heating Platen (L.R. X F.B.) |
mm |
400 X 400 |
450 X 500 |
450 X 500 |
570 X 610 |
700 X 700 |
800 X 800 |
|
|
Daylight |
mm |
250 |
400~600 |
450~650 |
500~650 |
500~700 |
500~700 |
|
|
Stroke |
mm |
250 |
350 |
350 / 400 |
400 |
400 |
400 |
|
|
Mold Thickness |
mm |
150 |
50~400 |
100~600 |
100~600 |
100~650 |
100~650 |
|
