Rubber products compression molding machine which has high steel column style mechanism with high precision of parallelism. Adjustable daylight and various customzied demolding ways accommodates different height of molds.
Machine Type |
TYC-V-10 |
TYC-V-12 |
TYC-V-14 |
TYC-V-16 |
TYC-V-18 |
TYC-V-22 |
|
Clamping Force |
ton |
100 |
150 |
200 |
250 |
350 |
500 |
Heating Platen Size (L.R. x F.B.) |
mm |
405x430 |
450x480 |
505x510 |
570x610 |
700x700 |
700x700 / 800x800 |
Daylight (max.) |
mm |
300 |
|||||
Stroke (max.) |
mm |
250 |
|||||
Heater Capacity Per Station |
kW |
8.76 |
10.56 |
17.4 |
19.2 |
22.6 |
22.6/39.2 |
Connection Station Per Set |
1-4 |
1-2 |
|||||
Turnover Degree |
。 |
45° |
|||||
Piston Diameter |
mm |
250 |
300 |
355 |
400 |
457.2 |
560 |
Vacuum Stroke |
mm |
160 |
160 |
160 |
200 |
200 |
200 |
Remarks: Custom design available.
