- Safety Guarding with interlock plugs for operator protection.
- Safety Light Curtain TYPE 4 to comply with CE regulations.
|
Machine Type |
TYC-V-10 |
TYC-V-12 |
TYC-V-14 |
TYC-V-16 |
TYC-V-18 |
TYC-V-22 |
|
|
Clamping Force |
ton |
100 |
150 |
200 |
250 |
350 |
500 |
|
Heating Platen Size (L.R. x F.B.)
|
mm |
405x430 |
450x480 |
505x510 |
570x610 |
700x700 |
700x700 / 800x800 |
|
Daylight (max.) |
mm |
300 |
|||||
|
Stroke (max.) |
mm |
250 |
|||||
|
Heater Capacity Per Station |
kW |
8.76 |
10.56 |
17.4 |
19.2 |
22.6 |
22.6/39.2 |
|
Connection Station Per Set |
1-4 |
1-2 |
|||||
|
Turnover Degree |
。 |
45° |
|||||
|
Piston Diameter |
mm |
250 |
300 |
355 |
400 |
457.2 |
560 |
|
Vacuum Stroke |
mm |
160 |
160 |
160 |
200 |
200 |
200 |
Remarks: Custom design available.
