Classification : PRODUCTS
Country: Taiwan
Phone: 886-6-2531251
Fax: 886-6-2535271
Contact Person: Ping Shun Huang
- Suitable to be used in the molding process of double color of melamine、urea、bakelite、cup...etc.
SPEC | TYPE | FCE-100 | FCE-150 | FCE-200 | FCE-300 |
---|---|---|---|---|---|
CLAMPING FORCE | TON | 100 | 150 | 200 | 300 |
PLATE SIZE | MM | 1200x530 | 1350x650 | 1500x720 | 1880x860 |
MM | 600x530 | 650x650 | 720x720 | 915x860 | |
STROKE | MM | 460 | 500 | 500 | 550 |
DAYLIGHT | MM | 650 | 700 | 700 | 800 |
OIL TANK CAPACITY | GAL | 70 | 70 | 100 | 100 |
PUMP PRESSURE | KGF/CM2 | 210 | 210 | 210 | 210 |
MOTOR | HP | 5 | 7.5 | 7.5 | 10 |
KW | 4 | 5.5 | 5.5 | 7.5 | |
HEATER CAPACITY | KW | 12 | 15 | 18 | 30 |
L | 2530 | 2635 | 2820 | 3250 | |
MACHINE DIMENSIONS | W | 1750 | 1900 | 2000 | 2200 |
H | 2200 | 2450 | 2600 | 2800 | |
MACHINE WEIGHT | KG | 4600 | 2375 | 6800 | 1100 |
L | 3000 | 2375 | 3000 | 3400 | |
WRAPPING SIZE | W | 1850 | 2000 | 2100 | 2300 |
H | 2300 | 2600 | 2750 | 3100 | |
WRAPPING WEIGHT APPROX | KG | 4750 | 6400 | 7600 | 1150 |
