Three Layer Co-Extrusion Cast Film Line

Classification : Multi-layer Co-extrusion Cast Film Machines

Country:

Phone: 886-6-2532157

Fax: 886-6-2533079

Contact Person: Susan Wei

Basic Specifications:
Resin	PP
Film width	3000mm (max.)
Film thickness	0.020~0.050mm
Line speed	200M/Min. (Max.)
Extruder A & C	90 mm dia. Screw L/D=30:1
Extruder B	125mm dia. Screw L/D=30:1
Drive for Extruder A & C	125 HP AC motor with vector inverter control
Drive for Extruder B	200 HP AC motor with vector inverter control
Extrusion output	800 KG/HR (Max.)
Production output	600 KG/HR (Max.) for 0.03mm x 3000mm
Extrusion die	1 set, EDI, ex USA
Casting unit roller	800mmφ x 3400mm width
Oscillating unit	1 set
Winding unit	1 set
Electric control panel
