Three Layer Co-Extrusion Abs Sheet Extrusion Line

ABS , 70% VG + 30% RG

Sheet for forming purpose used for refrigerator

1800mm (max.) x 1 sheet

0.6mm - 2.5mm

0.6～6.0 m/min. Mechanical possibility

60kg/hr

100mmφ Screw, L/D=32:1  x1 set for A layer

150mmφ Screw, L/D=32:1  x1 set for B layer

125 HP, extrusion output 300 kg/hr

200 KW, extrusion output 500 kg/hr

800 kg/hr (max., based on 100% virgin grade)

1 set, FKI-TYPE, Co-extrusion type

Up-stack, 90 degree configuration

500mmφ x 2100mm width x 3 pcs

Three (3) individual closed loop system x 1 set

Main haul-off roller

Main haul-off roller
