3 Lines T-Shirt Bag Making Machine / ST-88-L3S-400 / ST-88-L3-300 / ST-88-L3-400

Classification : T-shirt Bag Making Machines

COSMO MACHINERY CO., LTD.

Country: Taiwan

Phone: 886-2-86782865~8 (214)

Fax: 886-2-86782869

Contact Person: Mr. Yarzar

Video Inquiry Now

3 Lines production
1 servo driven system for non printed bag, 3 servo driven system for printed bag
Computer control over the entire process
From film roll to final bag, one process flow
Servo motor, as standard attachment, makes it easy to adjust the bag length and the production speed
Automatic film feeding, coordination free from tension adjustment
Automatically stop when running out of film/ film feeding blocks or bags jam/ color scanning misses
High production efficiency to save manpower and time

MODEL	ST - 88 - L3S-400
Production Size	Length : 350 ~ 650 mm Width : 160 ~ 365 mm Thickness : 8 ~ 50 um
Production Speed	150 ~ 250 pcs / min / line
Film Roll Size	Ø 900 x 365 mm
Power	220 V, 3 Phases, 50 / 60 HZ, 20 KVA
Heat	8 KW
Dimension	L : 5500 mm W : 1950 mm H : 1800 mm
Air Compressor	6 HP ( not included )
