Classification : Stretch Re-winder
Country: Taiwan
Phone: 886-2-86782865~8 (214)
Fax: 886-2-86782869
Contact Person: Mr. Yarzar
- Computer control over the entire process
- From film roll to final product, one process flow
- Automatically core changing system
MODEL | SWCR-350-L2 |
Finished Roll Dia | Ø 100 mm |
Available Mother Roll Width | 150 mm - 300 mm x Ø750 (max) |
Material Thickenss | 0.010 - 0.018 mm |
Finished Product Core Dia (outter) | Ø 25 - 50 mm |
Max Product speed | 500 meter / min / line |
Dimension L x W x H | 2320 x 1450 x 1950 mm |
Production Piece | 20 meter 10 pcs / min / line |
30 meter 8 pcs / min / line | |
60 meter 5 pcs / min / line | |
Power | 220V, 3Phases, 50/60HZ, 10KVA |
Weight | 1500 kg(net) / 1600 kg(gross) |
Required Air Compressor | 3HP (not included) |
* The specification are subject to be changed for improvement without notice.
